Siemens 6GK6015-0AL20-0PJ0 – RUGGEDCOM RX1500PN M12 X CG04B Line Module 8 PIN M12…

Name: Siemens 6GK6015-0AL20-0PJ0 – RUGGEDCOM RX1500PN M12 X CG04B Line Module 8 PIN M12…
Brand: Siemens
SKU: 6GK6015-0AL20-0PJ0

MPN: 6GK6015-0AL20-0PJ0 · Brand: Siemens

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Accessories for Ethernet Layer 3 switches and routers
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.3 kg
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can 6GK6015-0AL20-0PJ0 be shipped?

6GK6015-0AL20-0PJ0 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 6GK6015-0AL20-0PJ0 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 6GK6015-0AL20-0PJ0 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6GK6015-0AL20-0PJ0, subject to availability and destination.

RUGGEDCOM RX1500PN M12 X CG04B Line Module 8 PIN M12 X-CODED Copper Ethernet Modules 2x 10/100/1000TX 8-pin x-coded M12 with controlled bypass

Specifications

interfaces

number of electrical/optical connections / for network components or terminal equipment / maximum	2
number of electrical connections – for network components or terminal equipment / maximum	2
number of 10/100/1000 Mbit/s M12 ports	2
type of electrical connection – for network components or terminal equipment	M12

ambient conditions

ambient temperature – during operation	-40 ... +85 °C
ambient temperature – during storage	-40 ... +85 °C
ambient temperature – during transport	-40 ... +85 °C
ambient temperature – note	A maximum operating temperature of +85 °C is permissible for a duration of 16 hours
relative humidity / at 25 °C / without condensation / during operation / maximum	95 %
protection class IP	IP40

design, dimensions and weights

design	Media module
width	20 mm
height	115 mm
depth	180 mm
net weight	0.35 kg
product feature / conformal coating	No
fastening method	screwed
installation in media module slot	Yes

standards, specifications, approvals

standard – for EMC	FCC Part 15 (Class A), EN55022 (CISPR22 Class A)
standard – for safety / from CSA and UL	UL 60950-1, CSA C22.2 No. 60950-7
standard – for hazardous zone / from CSA and UL	Hazardous Locations: Class 1 Division 2
standard – for emitted interference	EN 61000-6-4 (Class A)
standard – for interference immunity	EN 61000-6-2
certificate of suitability	EN 61000-6-2, EN 61000-6-10
CE marking	Yes
C-Tick	No
KC approval	No
E1 approval	No
railway application in accordance with EN 50155	Yes
railway application in accordance with EN 50124-1	Yes
IEC 61850-3	Yes

standards, specifications, approvals / Environmental Product Declaration

Environmental Product Declaration	Yes
global warming potential [CO2 eq] – total	259.55 kg
global warming potential [CO2 eq] – during manufacturing	13.3 kg
global warming potential [CO2 eq] – during operation	246.21 kg
global warming potential [CO2 eq] – after end of life	0.04 kg

security information

Siemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement - and continuously maintain - a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7)
