Siemens 6GK6015-0AL11-0AA1
RUGGEDCOM RX1500PN PS 24 Power Supply 24VDC (15-36VDC), screw terminal block Conformal Coating
- MPN
- 6GK6015-0AL11-0AA1
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 6GK6015-0AL11-0AA1?
RUGGEDCOM RX1500PN PS 24 Power Supply 24VDC (15-36VDC), screw terminal block Conformal Coating
Specifications
General
| product brand name | RUGGEDCOM |
| Technical Product Detail Page | https://i.siemens.com/1P6GK6015-0AL11-0AA1 |
| suitability for operation | RX15xx |
electrical data / input
| supply voltage / 1 / rated value | 24 V |
| supply voltage / 1 / rated value — supply voltage / 1 / rated value | 15 ... 36 V |
| supply voltage / 1 / rated value — type of voltage / 1 / of the supply voltage | DC |
interfaces
| number of electrical connections — for power supply | 1 |
| number of electrical connections — for signaling contact | 1 |
| type of electrical connection — for power supply | 3 pole terminal block, permanently installed, screw contact |
| type of electrical connection — for signaling contact | 3 pole terminal block, permanently installed, plug contact |
signal inputs/outputs
| product component / signaling contact | Yes |
| relay design | Relay with form-C contact (CO, change over) |
| number of relay outputs / as CO contact | 1 |
| operating voltage / of the signaling contacts — at AC / maximum | 250 V |
| operating voltage / of the signaling contacts — at DC / maximum | 30 V |
| operational current / of the signaling contacts — at AC / at 250 V / maximum | 6.25 A |
| operational current / of the signaling contacts — at DC / at 30 V / maximum | 5 A |
design, dimensions and weights
| design | removable module |
| net weight | 0.55 kg |
| fastening method — screw connection | Yes |
ambient conditions
| ambient temperature — during operation | -40 ... +85 °C |
| ambient temperature — during storage | -40 ... +85 °C |
| ambient temperature — during transport | -40 ... +85 °C |
| ambient temperature — note | A maximum operating temperature of +85 °C is permissible for a duration of 16 hours |
| relative humidity / at 25 °C / without condensation / during operation / maximum | 95 % |
| protection class IP | IP30 |
standards, specifications, approvals
| standard — for EMC | FCC Part 15 (Class A), EN55022 (CISPR22 Class A) |
| standard — for safety / from CSA and UL | UL 60950-1, CSA C22.2 No. 60950-7 |
| standard — for emitted interference | EN 61000-6-4 (Class A) |
| standard — for interference immunity | EN 61000-6-2 |
| certificate of suitability | EN 61000-6-2, EN 61000-6-10 |
| certificate of suitability — relating to NEMA | TS 2 |
| certificate of suitability — CE marking | Yes |
| certificate of suitability — IEC 61850-3 | Yes |
| certificate of suitability — IEEE 1613 | Yes |
standards, specifications, approvals / hazardous environments
| standard / for hazardous zone / from CSA and UL | Hazardous Locations: Class 1 Division 2 |
further information / internet links
| internet link — to website: Selection guide for cables and connectors | https://support.industry.siemens.com/cs/ww/en/view/109766358 |
| internet link — to website: Industrial communication | https://www.siemens.com/simatic-net |
| internet link — to website: Siemens RUGGEDCOM | https://www.siemens.com/ruggedcom |
| internet link — to web page: SiePortal | https://sieportal.siemens.com/ |
| internet link — to website: Image database | https://www.automation.siemens.com/bilddb |
| internet link — to website: CAx-Download-Manager | https://www.siemens.com/cax |
| internet link — to website: Industry Online Support | https://support.industry.siemens.com |
security information
| security information | Siemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement - and continuously maintain - a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7) |
