Siemens 6ES7672-7AC01-0YG0
SIMATIC S7-1500, Software Controller CPU 1507S single license for 1 installation, runtime software, software
- MPN
- 6ES7672-7AC01-0YG0
- Category
- CPU 1507S Windows
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 6ES7672-7AC01-0YG0?
SIMATIC S7-1500, Software Controller CPU 1507S single license for 1 installation, runtime software, software, documentation and license key download, runtime software class A, 6 languages (de,en,it,fr,es,zh), executable in Windows 7 and Windows 10; reference hardware: SIMATIC IPC2x7E, IPC4x7E, IPC4x7D, IPC6x7E, IPC6x7D, IPC8x7E, IPC8x7D - - consignee email address required for delivery
Specifications
General information
| Product type designation | CPU 1507S |
| Software version | V21.9 |
| I&M data | Yes; I&M0 to I&M3 |
| STEP 7 TIA Portal configurable/integrated from version | V17 |
Configuration control
| via dataset | Yes |
Storage
| SIMATIC memory card required | No; Use of the PC mass storage |
| integrated (for program) | 5 Mbyte |
| integrated (for data) | 20 Mbyte |
| integrated (for CPU function library of CPU Runtime) | 50 Mbyte |
| integrated (on PC mass storage) | 320 Mbyte |
| with UPS | Yes; all memory areas declared retentive |
| with non-volatile memory | Yes; Depending on PC hardware |
CPU processing times
| for bit operations, typ. | 1 ns; On IPC427E, Intel Xeon processor |
| for word operations, typ. | 2 ns; On IPC427E, Intel Xeon processor |
| for fixed point arithmetic, typ. | 2 ns; On IPC427E, Intel Xeon processor |
| for floating point arithmetic, typ. | 2 ns; On IPC427E, Intel Xeon processor |
CPU-blocks
| Number of elements (total) | 6 000; In addition to blocks such as DBs, FBs and FCs, UDTs, global constants, etc. are also regarded as elements |
| Number, max. | 5 999; Number range: 1 to 65535 |
| Size, max. | 16 Mbyte |
| Number, max. | 5 998; Number range: 1 to 65535 |
| Size, max. | 1 024 kbyte |
| Number, max. | 5 999; Number range: 1 to 65535 |
| Size, max. | 1 024 kbyte |
| Size, max. | 1 024 kbyte |
| Number of free cycle OBs | 100 |
| Number of time alarm OBs | 20 |
| Number of delay alarm OBs | 20 |
| Number of cyclic interrupt OBs | 20 |
| Number of process alarm OBs | 50 |
| Number of DPV1 alarm OBs | 3 |
| Number of isochronous mode OBs | 1 |
| Number of technology synchronous alarm OBs | 2 |
| Number of startup OBs | 100 |
| Number of asynchronous error OBs | 4 |
| Number of synchronous error OBs | 2 |
| Number of diagnostic alarm OBs | 1 |
| per priority class | 24 |
Counters, timers and their retentivity
| Number | 2 048 |
| — adjustable | Yes |
| Number | Any (only limited by the main memory) |
| — adjustable | Yes |
| Number | 2 048 |
| — adjustable | Yes |
| Number | Any (only limited by the main memory) |
| — adjustable | Yes |
Data areas and their retentivity
| Retentive data area (incl. timers, counters, flags), max. | 135 kbyte; on SIMATIC IPC227E, IPC277E, IPC427D, IPC477D, IPC427E, IPC477E, IPC627E, IPC677E; 35 KB on SIMATIC IPC627D, IPC677D and IPC827D |
| Extended retentive data area (incl. timers, counters, flags), max. | 20 Mbyte; When using PC mass storage for retentive data |
| Size, max. | 16 kbyte |
| Number of clock memories | 8; in 1 memory byte |
| Retentivity adjustable | Yes |
| Retentivity preset | No |
| per priority class, max. | 64 kbyte; max. 16 KB per block |
Address area
| Number of IO modules | 8 192 |
| Inputs | 32 kbyte |
| Outputs | 32 kbyte |
| Number of subprocess images, max. | 32 |
Hardware configuration
| Number of distributed IO systems | 20 |
| via PC interfaces | 1 |
| via PC interfaces | 1; any combination of RT or IRT interfaces |
Time of day
| Type | Software clock, synchronizable, no battery backup |
| Deviation per day, max. | Depending on PC hardware |
| Number | 16 |
| supported | Yes |
| to DP, master | No |
| on Ethernet via NTP | Yes |
| on Windows clock, device | Yes |
Interfaces
| Number of interfaces | 3 |
| Number of PROFINET interfaces | 2; Of which one interface can be used as an IO Controller or I-Device |
| Number of PROFIBUS interfaces | 1 |
1. Interface
| Interface type | CP 1625 |
| Number of connections | 128 |
| RJ 45 (Ethernet) | Yes |
| — Transmission rate, max. | 100 Mbit/s |
| — Industrial Ethernet status LED | Yes |
| Number of ports | 2 |
| integrated switch | Yes |
| PROFINET IO Controller | Yes |
| PROFINET IO Device | Yes |
| SIMATIC communication | Yes |
| Open IE communication | Yes; Optionally also encrypted |
| Web server | Yes |
| Media redundancy | Yes; MRP Automanager according to IEC 62439-2 Edition 2.0 |
| — Isochronous mode | Yes |
| — Direct data exchange | Yes; Requirement: IRT and isochronous mode (MRPD optional) |
| — shortest clock pulse | 500 µs |
| — IRT | Yes |
| — PROFIenergy | Yes |
| — Prioritized startup | Yes; max. 32 PROFINET devices; if you want to use the "Prioritized startup" functionality in STEP 7 for the PROFINET interface of the CPU, the CPU and the device must be seperated by means of a switch (e.g SCALANCE X205) or CP1625 |
| — Number of connectable IO Devices, max. | 256 |
| — Of which IO devices with IRT, max. | 64 |
| — Number of connectable IO Devices for RT, max. | 256 |
| — of which in line, max. | 256 |
| — Number of IO Devices that can be simultaneously activated/deactivated, max. | 8 |
| — IO Devices changing during operation (partner ports), supported | Yes; the CPU and changing IO devices must be separated by a switch (e.g. SCALANCE X205) |
| — Number of IO Devices per tool, max. | 8 |
| — Updating times | The minimum value of the update time also depends on communication share set for PROFINET IO, on the number of IO devices, and on the quantity of configured user data |
| — for send cycle of 250 µs | 250 µs to 4 ms |
| — for send cycle of 500 µs | 500 µs to 8 ms |
| — for send cycle of 1 ms | 1 ms to 16 ms |
| — for send cycle of 2 ms | 2 ms to 32 ms |
| — for send cycle of 4 ms | 4 ms to 64 ms |
| — With IRT and parameterization of "odd" send cycles | Update time = set "odd" send clock (any multiple of 125 µs: 375 µs, 625 µs ... 3 875 µs) |
| — for send cycle of 250 µs | 250 µs to 128 ms |
| — for send cycle of 500 µs | 500 µs to 256 ms |
| — for send cycle of 1 ms | 1 ms to 512 ms |
| — for send cycle of 2 ms | 2 ms to 512 ms |
| — for send cycle of 4 ms | 4 ms to 512 ms |
| — Inputs, max. | 8 kbyte |
| — Outputs, max. | 8 kbyte |
| — PG/OP communication | Yes |
| — Isochronous mode | No |
| — IRT | Yes |
| — PROFIenergy | Yes |
| — Prioritized startup | Yes; if you want to use the "Prioritized startup" functionality in STEP 7 for the PROFINET interface of the CPU, the CPU and the device must be separated by means of a switch (e.g. SCALANCE X205) |
| — Shared device | Yes |
| — Number of IO Controllers with shared device, max. | 4 |
| — Asset management record | Yes |
2. Interface
| Interface type | Onboard PROFINET / IE interface X2/X3 of the SIMATIC IPC, Intel Springville i210T |
| Number of connections | 128 |
| RJ 45 (Ethernet) | Yes |
| — Transmission rate, max. | 100 Mbit/s |
| — Industrial Ethernet status LED | Yes |
| Number of ports | 1 |
| integrated switch | No |
| PROFINET IO Controller | Yes |
| PROFINET IO Device | Yes |
| SIMATIC communication | Yes |
| Open IE communication | Yes |
| Web server | Yes |
| Media redundancy | No |
| — Isochronous mode | No |
| — IRT | No |
| — PROFIenergy | Yes |
| — Prioritized startup | Yes; max. 32 PROFINET devices; if you want to use the "Prioritized startup" functionality in STEP 7 for the PROFINET interface of the CPU, the CPU and the device must be separated by means of a switch (e.g. SCALANCE X205) |
| — Number of connectable IO Devices for RT, max. | 128 |
| — of which in line, max. | 128 |
| — Number of IO Devices that can be simultaneously activated/deactivated, max. | 8 |
| — Number of IO Devices per tool, max. | 8 |
| — Updating times | The minimum value of the update time also depends on communication share set for PROFINET IO, on the number of IO devices, and on the quantity of configured user data |
| — Inputs, max. | 8 kbyte |
| — Outputs, max. | 8 kbyte |
| — Isochronous mode | No |
| — IRT | No |
| — PROFIenergy | Yes |
| — Shared device | Yes |
| — Number of IO Controllers with shared device, max. | 4 |
| — Asset management record | Yes |
3. Interface
| Interface type | PROFIBUS with CP 5622, CP 5622 onboard |
| Number of connections | 44 |
| RS 485 | Yes |
| PROFIBUS DP master | Yes |
| PROFIBUS DP device | No |
| SIMATIC communication | Yes; no PG/STEP 7 connection possible |
| max. number of DP devices | 64 |
| — Equidistance | No |
| — Isochronous mode | No |
| — Inputs, max. | 8 kbyte |
| — Outputs, max. | 8 kbyte |
4. Interface
| Interface type | PROFIBUS with CP 5623 |
| Number of connections | 44 |
| RS 485 | Yes |
| PROFIBUS DP master | Yes |
| PROFIBUS DP device | No |
| SIMATIC communication | Yes; no PG/STEP 7 connection possible |
| max. number of DP devices | 125 |
| — Equidistance | No |
| — Isochronous mode | No |
| — Inputs, max. | 8 kbyte |
| — Outputs, max. | 8 kbyte |
Protocols
| PROFIsafe | No |
| Number of connections, max. | 128 |
| Number of connections reserved for ES/HMI/web | 10 |
| Number of S7 routing paths | 16 |
| — MRP | Yes |
| — MRPD | Yes; Requirement: IRT |
| — Switchover time on line break, typ. | 200 ms; For MRP, bumpless for MRPD |
| — Number of stations in the ring, max. | 50 |
| PG/OP communication | Yes |
| S7 routing | Yes |
| S7 communication, as server | Yes |
| S7 communication, as client | Yes |
| User data per job, max. | 64 kbyte; BSEND/BRCV: 64 KB; PUT/GET: 960 bytes |
| TCP/IP | Yes |
| — Data length, max. | 64 kbyte |
| ISO-on-TCP (RFC1006) | Yes |
| — Data length, max. | 64 kbyte |
| UDP | Yes |
| — Data length, max. | 2 kbyte |
| — UDP multicast | Yes; 128 multicast circuits (of which max. 5 via CP 1625) |
| DHCP | Yes |
| DNS | Yes |
| SNMP | Yes |
| DCP | Yes |
| LLDP | Yes |
| HTTP | Yes; Standard and user pages |
| HTTPS | Yes; Standard and user pages |
| Runtime license required | Yes; "Medium" license required |
| OPC UA Client | Yes; Data access (read, write), method call |
| — Application authentication | Yes |
| — Security policies | Yes; Available security policies: None, Basic128Rsa15, Basic256Rsa15, Basic256Sha256 |
| — User authentication | Yes; "anonymous" or by user name & password |
| — Number of connections, max. | 40 |
| — Number of nodes of the client interfaces, recommended max. | 5 000 |
| — Number of elements for one call of OPC_UA_NodeGetHandleList/OPC_UA_ReadList/OPC_UA_WriteList, max. | 300 |
| — Number of elements for one call of OPC_UA_NameSpaceGetIndexList, max. | 20 |
| — Number of elements for one call of OPC_UA_MethodGetHandleList, max. | 100 |
| — Number of simultaneous calls of the client instructions for session management, per connection, max. | 1 |
| — Number of simultaneous calls of the client instructions for data access, per connection, max. | 5 |
| — Number of registerable nodes, max. | 5 000 |
| — Number of registerable method calls of OPC_UA_MethodCall, max. | 100 |
| — Number of inputs/outputs when calling OPC_UA_MethodCall, max. | 20 |
| OPC UA Server | Yes; Data access (read, write, subscribe), method call, custom address space |
| — Application authentication | Yes |
| — Security policies | Yes; Available security policies: None, Basic128Rsa15, Basic256Rsa15, Basic256Sha256 |
| — User authentication | Yes; "anonymous" or by user name & password |
| — Number of sessions, max. | 64 |
| — Number of accessible variables, max. | 200 000 |
| — Number of registerable nodes, max. | 50 000 |
| — Number of subscriptions per session, max. | 20 |
| — Sampling interval, min. | 10 ms |
| — Publishing interval, min. | 10 ms |
| — Number of server methods, max. | 100 |
| — Number of inputs/outputs per server method, max. | 20 |
| — Number of monitored items, recommended max. | 10 000; for 1 s sampling interval and 1 s send interval |
| — Number of server interfaces, max. | 10 |
| — Number of nodes for user-defined server interfaces, max. | 30 000 |
| MODBUS | Yes; MODBUS TCP |
S7 message functions
| Number of login stations for message functions, max. | 32 |
| Program alarms | Yes |
| Number of configurable program messages, max. | 10 000 |
| Number of loadable program messages in RUN, max. | 5 000 |
| Number of simultaneously active program alarms | 1 000 |
| Number of program alarms | 1 000 |
| Number of alarms for system diagnostics | 200 |
| Number of alarms for motion technology objects | 160 |
Test commissioning functions
| Joint commission (Team Engineering) | Yes; Parallel online access possible for up to 10 engineering systems |
| Status block | Yes; up to 8 simultaneously |
| Single step | Yes |
| Number of breakpoints | 8 |
| Status/control variable | Yes |
| Variables | Inputs, outputs, memory bits, DB, times, counters |
| Number of variables, max. – — of which status variables, max. | 200 |
| Number of variables, max. – — of which control variables, max. | 200 |
| Number of variables, max. – Forcing | Yes |
| Number of variables, max. – Forcing, variables | Inputs, outputs |
| Number of variables, max. – Number of variables, max. | 200 |
| Number of variables, max. – present | Yes |
| Number of variables, max. – Number of entries, max. | 1 000 |
| Number of variables, max. – — of which powerfail-proof | 300 |
| Number of variables, max. – Number of configurable Traces | 4 |
| Number of variables, max. – Memory size per trace, max. | 512 kbyte |
Interrupts/diagnostics/status information
| RUN/STOP LED | Yes; HW LED of SIMATIC IPC227E, IPC427D/E, IPC627D/E, IPC827D, IPC677D/E |
| ERROR LED | Yes; HW LED of SIMATIC IPC227E, IPC427D/E, IPC627D/E, IPC827D, IPC677D/E |
| MAINT LED | Yes; HW LED of SIMATIC IPC227E, IPC427D/E, IPC627D/E, IPC827D, IPC677D/E |
Supported technology objects
| Motion Control | Yes; Note: The number of technology objects affects the cycle time of the PLC program; selection guide via the TIA Selection Tool or SIZER |
| Number of available Motion Control resources for technology objects | 4 800 |
| Required Motion Control resources – — per speed-controlled axis | 40 |
| Required Motion Control resources – — per positioning axis | 80 |
| Required Motion Control resources – — per synchronous axis | 160 |
| Required Motion Control resources – — per external encoder | 80 |
| Required Motion Control resources – — per output cam | 20 |
| Required Motion Control resources – — per cam track | 160 |
| Required Motion Control resources – — per probe | 40 |
| Positioning axis – — Number of positioning axes at motion control cycle of 4 ms (typical value) | 30; On IPC427E, Intel Xeon processor |
| Positioning axis – — Number of positioning axes at motion control cycle of 8 ms (typical value) | 60; On IPC427E, Intel Xeon processor |
| Controller – PID_Compact | Yes; Universal PID controller with integrated optimization |
| Controller – PID_3Step | Yes; PID controller with integrated optimization for valves |
| Controller – PID-Temp | Yes; PID controller with integrated optimization for temperature |
| Counting and measuring – High-speed counter | Yes |
Hardware requirement
| Hardware required | SIMATIC IPC2x7E, IPC4x7D/E, IPC6x7D/E, IPC8x7D/E |
| Single-core processor | No |
| Single-core processor with hyper-threading | No |
| Multi-core processor | Yes |
| Multi-core processor with hyper-threading | Yes |
| occupied cores | 1; For multicore processors with activated Hyper-Threading, one complete physical core is reserved for the CPU 1507S |
| Work memory, min. | 4 Gbyte |
| Hard disk memory required for installation | 720 Mbyte |
| Temporary hard disk memory for installation | 230 Mbyte |
| Hard disk memory required at runtime | 400 Mbyte |
Operating systems
| Windows 7 | Yes; Professional, Enterprise, Ultimate (32 bit and 64 bit); Windows Embedded Standard 7 with delivery image of the SIMATIC IPC |
| Windows 10 | Yes; Windows 10 Enterprise 2016 LTSB, 64-bit, MUI on IPC2x7E, IPC4x7E, IPC6x7D, IPC8x7D; Windows 10 Enterprise 2019 LTSC 64-bit, MUI on IPC2x7E, IPC4x7E, IPC6x7E, IPC8x7E |
Configuration
| — LAD | Yes |
| — FBD | Yes |
| — STL | Yes |
| — SCL | Yes |
| — CFC | No |
| — GRAPH | Yes |
| User program protection/password protection | Yes |
| Copy protection | Yes |
| Block protection | Yes |
| Protection level: Write protection | Yes |
| Protection level: Read/write protection | Yes |
| Protection level: Complete protection | Yes |
| lower limit | adjustable minimum cycle time |
| upper limit | adjustable maximum cycle time |
| Size of ODK SO file, max. | 9.8 Mbyte |
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
6ES7672-7AC01-0YG0: frequently asked questions
When can 6ES7672-7AC01-0YG0 be shipped?
6ES7672-7AC01-0YG0 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 6ES7672-7AC01-0YG0 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 6ES7672-7AC01-0YG0 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6ES7672-7AC01-0YG0, subject to availability and destination.
More Siemens parts
Siemens 6ES7672-7AC01-0YG0Price and lead time confirmed within 1 business day
Request a Quote
