Siemens 6AV7860-1EX02-0AA1
SIMATIC Flat Panel accessory, USB-Link tranceiver, Use with Flat Panel extended with cabling sets >5m
- MPN
- 6AV7860-1EX02-0AA1
- Category
- HMI & Operator Panels
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 6AV7860-1EX02-0AA1?
SIMATIC Flat Panel accessory, USB-Link tranceiver, Use with Flat Panel extended with cabling sets >5m, Attention! Not suitable for PCU50 und PC627B/C
Specifications
General information
| Product type designation | USB link transceiver, host unit |
Installation type/mounting
| Wall mounting/direct mounting | Yes |
Supply voltage
| Design of the power supply | via USB |
| Type of supply voltage | DC |
| Rated value (DC) | 5 V |
Power loss
| Power loss, typ. | 0.5 W |
Interfaces
| HMI-side interface | USB link (CAT5) |
| Device-side interface | USB 1.2 |
Ambient conditions
| Ambient temperature during operation — min. | 5 °C |
| Ambient temperature during operation — max. | 50 °C |
| Ambient temperature during storage/transportation — min. | -20 °C |
| Ambient temperature during storage/transportation — max. | 60 °C |
Weights
| Weight, approx. | 3 kg |
Scope of supply
| Delivery quantity in pieces | 1 |
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
6AV7860-1EX02-0AA1: frequently asked questions
When can 6AV7860-1EX02-0AA1 be shipped?
6AV7860-1EX02-0AA1 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 6AV7860-1EX02-0AA1 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 6AV7860-1EX02-0AA1 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6AV7860-1EX02-0AA1, subject to availability and destination.
