Siemens 6AV6381-2BH08-1AX0
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | SIMATIC WinCC V7/V8 basic software |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 2.67 kg |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
When can 6AV6381-2BH08-1AX0 be shipped?
6AV6381-2BH08-1AX0 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 6AV6381-2BH08-1AX0 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 6AV6381-2BH08-1AX0 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6AV6381-2BH08-1AX0, subject to availability and destination.
WinCC system software V8.1, RT 8192 (8192 PowerTags), runtime software, single license, software and documentation on DVD, license key on USB flash drive, class A, 5 languages (de,en,fr,es,it), please observe product release: support.industry.siemens.com SIOS entry ID: 109973487 - - content: set (2x DVD + 1x USB)
Specifications
Operator control and monitoring
| Object block library | Yes |
| Alarm system (incl. buffer and acknowledgment) | Yes |
| Report system/log system | Yes |
| SQL database | Yes |
| Process diagnostics | No |
| SCADA functionality | Yes |
| Sector-specific and technological expansions | Yes |
| User archive/recipe management | Yes |
Interfaces
| Programming interfaces | Yes |
| OPC-DA interface, Server | Yes |
| OPC-DA interface, Client | Yes |
Hardware requirement
| Processor cycle frequency, min. | 2.5 GHz |
| Main memory, min. | 4 Gbyte |
Operating systems
| Windows 2000 | No |
| Windows 2003 Server | No |
| Windows Vista | No |
| Windows XP | No |
| Windows 7 | No |
| Windows 8 | No |
| Windows 10 | Yes |
Configuration
| Online configuration | Yes |
| Number of multi-user configurations, max. | 32 |
| Number of Visual Basic Scripts | Yes |
| other | Yes |
| Password protection | Yes |
Languages
| Number of configuration languages | 70 |
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
| Product data sheet 6AV6381-2BH08-1AX0 |
