Siemens 5SJ6120-6KS
Miniature circuit breaker 230/400 V 6kA, 1-pole, B, 20 A, D=70 mm with screwless outgoing terminals
- MPN
- 5SJ6120-6KS
- Category
- Basic Devices
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Siemens 5SJ6120-6KS?
Miniature circuit breaker 230/400 V 6kA, 1-pole, B, 20 A, D=70 mm with screwless outgoing terminals
Specifications
Model
| product brand name | SENTRON |
| product designation | Miniature circuit breaker |
| design of the product | Miniature circuit breaker 5SJ6 |
General technical data
| number of poles | 1 |
| design of pole | 1P |
| tripping characteristic class | B |
| mechanical service life (operating cycles) typical | 20 000 |
| overvoltage category | 3 |
| degree of pollution | 2 |
Voltage
| insulation voltage (Ui) at AC rated value | 440 V |
| operational current at AC rated value | 20 A |
Supply voltage
| supply voltage — at AC | 400 V |
| supply voltage — at DC rated value | 60 V |
| operating voltage — with multi-phase operation at AC maximum | 440 V |
| operating voltage — at DC rated value maximum | 60 V |
| supply voltage frequency rated value | 50 Hz |
Protection class
| protection class IP | IP20, with connected conductors |
Breaking Capacity
| switching capacity current — according to EN 60898 rated value | 6 kA |
| switching capacity current — according to IEC 60947-2 rated value | 6 kA |
| energy limitation class | 3 |
Dissipation
| power loss [W] for rated value of the current at AC in hot operating state per pole | 2.2 W |
| suitability for operation | Residential buildings/infrastructure |
Product details
| product feature touch protection | Yes |
| product component neutral conductor switching | No |
| product feature halogen-free | Yes |
| product feature sealable | Yes |
| product feature silicon-free | Yes |
| product extension installable supplementary devices | No |
Connections
| connectable conductor cross-section on plug-type connection using the upper clamping point without core end processing — minimum | 1.5 mm² |
| connectable conductor cross-section on plug-type connection using the upper clamping point without core end processing — maximum | 4 mm² |
| connectable conductor cross-section solid — minimum | 0.75 mm² |
| connectable conductor cross-section solid — maximum | 25 mm² |
| connectable conductor cross-section stranded — minimum | 0.75 mm² |
| connectable conductor cross-section stranded — maximum | 25 mm² |
| connectable conductor cross-section finely stranded with core end processing — minimum | 1.5 mm² |
| connectable conductor cross-section finely stranded with core end processing — maximum | 2.5 mm² |
Mechanical Design
| height | 90 mm |
| width | 18 mm |
| depth | 76 mm |
| installation depth | 70 mm |
| number of modular width units | 1 |
| fastening method | DIN rail |
| mounting position | any |
| Net Weight | 127 g |
Environmental conditions
| influence of the surrounding temperature | Periodically +55°C, max. 95% humidity |
| ambient temperature during operation — minimum | -25 °C |
| ambient temperature during operation — maximum | 45 °C |
| ambient temperature during storage — minimum | -40 °C |
| ambient temperature during storage — maximum | 75 °C |
