Siemens 3ZS1316-4CC10-0YA5
SIRIUS engineering Safety ES V1.0 Basic license key on USB flash drive software on CD floating license for…
- MPN
- 3ZS1316-4CC10-0YA5
- Category
- SIRIUS Safety ES
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Siemens 3ZS1316-4CC10-0YA5?
SIRIUS engineering Safety ES V1.0 Basic license key on USB flash drive software on CD floating license for one user engineering software class A 3 languages (de,en,fr) executable in: Windows 10 64-bit Professional/Enterprise Windows 7 32/64-bit SP 1 Professional/Ultimate/Enterpris e reference hardware: SIRIUS MSS 3RK3 SIRIUS 3SK2 communication via system interface to PC (serial interface) content: set (1x DVD + 1x USB)
Specifications
General technical data
| product designation | Safety ES V1.0 |
| software version | V 1.0 |
| product description | Engineering software for 3SK2 and 3RK3 safety relays; BASIC license; integrated graphical editor; integrated diagnostics and commissioning support; connection via system interface; license key on USB stick |
| national language of the software | german / englisch / french |
| design of the product | Safety ES V1.0 Basic |
| product license | floating license for 1 user |
| software class | A |
| target system | SIRIUS MSS 3RK3, SIRIUS 3SK2 |
Features
| product component component library | No |
| product function diagnostics function | Yes |
| product function controlled positioning | No |
| product function simulation function | No |
| product function technological function | Yes |
| product function analysis function | No |
| product function movement function | No |
| product function data acquisition function | No |
| product function commissioning function | Yes |
| product function communication function | Yes |
| product function project planning function | Yes |
| Product function maintenance function | No |
| product function evaluation function | No |
| product function parameterizing function | Yes |
Requirements
| processor clock frequency minimum | 1 000 MHz |
| storage capacity — on hard disk required | 280 Mbyte |
| storage capacity — of the main memory or RAM minimum | 1 024 kbyte |
| design of the drive/storage medium required — CD-ROM | Yes |
| design of the drive/storage medium required — floppy disk | No |
| design of the drive/storage medium required — DVD drive | No |
| vertical image resolution of the graphics card | 768 pixel |
| horizontal image resolution of the graphics card | 1 024 pixel |
| number of colors of the graphics card | 256 |
| operating system required | Windows 7 SP1 64 Bit Ultimate / Professional / Enterprise (Standard installation); Windows 10 64 Bit Professional / Enterprise (Standard installation) |
| browser software required | no |
| viewer software required | no |
No matching specifications
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
3ZS1316-4CC10-0YA5: frequently asked questions
When can 3ZS1316-4CC10-0YA5 be shipped?
3ZS1316-4CC10-0YA5 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3ZS1316-4CC10-0YA5 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3ZS1316-4CC10-0YA5 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3ZS1316-4CC10-0YA5, subject to availability and destination.
