Siemens 3SU1960-0FA80-0AA0-Z Y19

Sealing plug for unused control points, 30 mm, metal matt, sand gray

MPN: 3SU1960-0FA80-0AA0-Z Y19
Category: Actuators

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Siemens parts? We buy surplus →

What is the Siemens 3SU1960-0FA80-0AA0-Z Y19?

Sealing plug for unused control points, 30 mm, metal matt, sand gray, customer-specific selection with SIRIUS ACT configurator (CIN)

Specifications

Actuator

shape of the actuating element	round
outer diameter of the actuating element	38 mm

General technical data

protection class IP	IP66, IP67, IP69(IP69K)
degree of protection NEMA rating	1, 2, 3, 3R, 4, 4X, 12
reference code according to IEC 81346-2	S
Substance Prohibitance (day/month/year)	10/01/2014
Net Weight	68.5 g

Ambient conditions

ambient temperature – during operation	70 ... -25 °C
ambient temperature – during storage and transport	-40 ... +80 °C
environmental category during operation according to IEC 60721	3M6, 3S2, 3B2, 3C3, 3K6 (with relative air humidity of 10 ... 95%)

Installation/ mounting/ dimensions

shape of the installation opening	round
mounting diameter	30.5 mm
positive tolerance of installation diameter	0.4 mm
mounting height	5.3 mm
installation width	38 mm
installation depth	31.3 mm

Accessories

material of accessory	Metal matt
color of accessory	sand gray

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet 3SU1960-0FA80-0AA0PDF

3SU1960-0FA80-0AA0-Z Y19: frequently asked questions

When can 3SU1960-0FA80-0AA0-Z Y19 be shipped?

3SU1960-0FA80-0AA0-Z Y19 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3SU1960-0FA80-0AA0-Z Y19 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3SU1960-0FA80-0AA0-Z Y19 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3SU1960-0FA80-0AA0-Z Y19, subject to availability and destination.
