Siemens 1PH8163-1MG23-0LZ2 Q1F – SIMOTICS M compact asynchronous motor 2000 r/min, 42 kW
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Servo & Motion Control |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 229 kg |
Shipping & availability
When can 1PH8163-1MG23-0LZ2 Q1F be shipped?
1PH8163-1MG23-0LZ2 Q1F is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1PH8163-1MG23-0LZ2 Q1F in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1PH8163-1MG23-0LZ2 Q1F and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1PH8163-1MG23-0LZ2 Q1F, subject to availability and destination.
SIMOTICS M compact asynchronous motor 2000 r/min, 42 kW, 201 Nm, 93 A, 335 V 2300 r/min, 48 kW, 199 Nm, 93 A, 382 V 2650 r/min, 55 kW, 198 Nm, 90 A, 450 V water cooling, degree of protection IP65 incremental encoder sin/cos 1 Vpp 2048 S/R with C and D track with temperature sensor Pt1000 type of construction IM B35 plain shaft without feather key bearing version: performance vibration class: special/B; shaft and flange accuracy: special terminal box (top) Q1F: special terminal box rotated customer-specific motor in accordance with CIGO no. 10113876
