Siemens 1PH8107-1CS02-3MZ2-Z Q2C+Y64+Y84 – SIMOTICS M compact asynchronous motor Y2000RPM, 11 kW
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Servo & Motion Control |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 75.5 kg |
Shipping & availability
When can 1PH8107-1CS02-3MZ2-Z Q2C+Y64+Y84 be shipped?
1PH8107-1CS02-3MZ2-Z Q2C+Y64+Y84 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1PH8107-1CS02-3MZ2-Z Q2C+Y64+Y84 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1PH8107-1CS02-3MZ2-Z Q2C+Y64+Y84 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1PH8107-1CS02-3MZ2-Z Q2C+Y64+Y84, subject to availability and destination.
SIMOTICS M compact asynchronous motor Y2000RPM, 11 kW, 53 Nm, 26.7 A, 368 V D5000RPM, 11 kW, 21 Nm, 28 A, 410 V forced ventilation; direction of air flow DE--> NDE; IP55 degree of protection incremental encoder sin/cos 1 Vpp plain hollow shaft; bearing version: high performance; S terminal box (top) Q2C: terminal box rotated by 180° cable outlet left signal line NDE on the face end Y64: prepared for rotary distributor with flange dimension 114H6 Y84: customer specification on rating plate customer-specific motor SMR-36-2015
