Schneider Electric TSXDSY08T22

Discrete output module Modicon Premium - 8 O solid state

MPN: TSXDSY08T22
EAN: 3389110717594
Category: Modicon Premium

Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original TSXDSY08T22 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric TSXDSY08T22?

Schneider Electric TSXDSY08T22 — discrete output module Modicon Premium - 8 O solid state. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon Premium Automation platform
Product or component type	Discrete output module
Discrete output number	8
Discrete output type	Solid state protected
Discrete output voltage	24 V DC positive conforming to EN/IEC 61131-2 19...30 V
Discrete output current	2 A

Complementary

Current per channel	2.5 A
Maximum current per module	14 A
Maximum leakage current	1 mA at state 0
[Ures] residual voltage	0.5 V
Response time	0.2 ms
Switching frequency	0.5/LI² Hz
Output overvoltage protection	By transil diode
Reverse polarity protection	Reverse mounted diode
Output overload protection	Electronic tripping on reactivation
Short-circuit protection	Electronic tripping on reactivation
Preactuator voltage detection threshold	16 V
Minimum load impedance	12 W
isalotion resistance	> 10 MOhm 500 V
Power dissipation	(1.3 W + 0.2 W x No of outputs x current per module)
Marking	CE
Electrical connection	Screw terminal block
Current consumption	55 mA at 5 V DC
Module format	Standard
Net weight	0.41 kg

Environment

Dielectric strength	1500 V 50/60 Hz 60 s
Standards	CSA C22.2 No 213 Class I Division 2 Group D; CSA C22.2 No 213 Class I Division 2 Group B; CSA C22.2 No 142; CSA C22.2 No 213 Class I Division 2 Group A; 93/68/EEC; 73/23/EEC; 92/31/EEC; UL 508; IEC 61131-2; CSA C22.2 No 213 Class I Division 2 Group C; 89/336/EEC
Product certifications	RINA; GL; RMRS; BV; ABS; LR; DNV
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-25…70 °C
Relative humidity	10…95 % without condensation for operation; 5…95 % without condensation for storage
Operating altitude	0...2000 m
Protective treatment	TC
IP degree of protection	IP20
Pollution degree	2
