What is the Schneider Electric SURT1000XLIM?

The APC Smart-UPS RT is an online UPS with a power rating of 1000VA and output power capacity of 700 watts. It operates at a nominal voltage of 230V and includes multiple output connections such as IEC 60320 and IEC Jumpers. This model is includes a lead-acid battery and is suitable for marine applications. The UPS features double conversion online technology and sine wave output.

Specifications

Specifications

PresentationHigh availability, ruggedized power protection for shipboard and other transportation applications.
Max. Capacity Used
Main Input Voltage230 V
Product or component typeUninterruptible power supply (UPS)
Other Input Voltage220 V, 240 V
Main Output Voltage230 V
Other Output Voltage220 V, 240 V
Rated power in W700 W
rated power in VA1000 VA
Input Connection TypeIEC 60320 C14
output connection type6 IEC 60320, 2 IEC Jumpers
Number of rack unit2U
Cable length2.5 m
Number of cables1
Provided equipmentCD with software, Relay board, Smart UPS signalling RS-232 cable, User manual
Run TimeView Runtime Graph
Battery typeLead-acid battery
Extended runtime1
Number of battery filled slots1
Number of battery free slots0
Battery recharge time3 h
Number of battery replacement quantity1
Battery life3…5 year(s)
Replacement batteryRBC31
Battery charger power109 W rated
Number of power module700
Number of power module filled slots0
Number of power module free slots0
RedundantNo
Variant optionShipboard
UPS typeOn-Line
ColourBlack
Height432 mm
Width85 mm
Depth483 mm
Net weight23 kg
Mounting locationFront
Mounting preferenceLower
Mounting modeRack-mounted
Two post mountable0
USB compatibleNo
Input Power Factor at Full Load1
Input voltage limits180...280 V
Network frequency50/60 Hz +/- 5 Hz auto-sensing
Bypass typeBuilt-in bypass
Crest factor3 : 1
Harmonic distortionLess than 3 %
Maximum configurable power in VA1000 VA
Maximum configurable power in W700 W
Wave typeSine wave
Efficiency88 % (full load)
Output frequency50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz sync to mains, 60 Hz +/- 0.1 % for 60 Hz nominal unsynchronised, 50 Hz +/- 0.1 % for 50 Hz nominal unsynchronised
Additional informationConfigurable for 220 : 230 or 240 nominal output voltage
Product certificationsCE, DNV, KCC
StandardsEN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018
Acoustic level55 dBA
Heat dissipation324 Btu/h
Operating altitude0...10000 ft
Ambient air temperature for operation0…55 °C
Ambient air temperature for storage-20…50 °C
Storage altitude0…15240 m
IP degree of protectionIP20
Relative humidity0…95 % non-condensing
Storage Relative Humidity0…95 % non-condensing
Emergency power offOptional
Free slots0
AlarmAlarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge energy rate420 J
Noise suppressionFull time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Packaging

Package 11 PCE, 59.4 cm × 63 cm × 28.6 cm (L × W × H), 27.8 kg
