RUZC200Maintaining clamp, Harmony Electromechanical Relays, for RUM sockets, metal
Schneider Electric RUZSC3M
Socket, Harmony Electromechanical Relays, for RUMC3 relays, 12A, screw connec to rs, separate contact
- MPN
- RUZSC3M
- EAN
- 3389119403238
- Category
- Harmony Electromechanical Relays
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric RUZSC3M?
"This Harmony RUM plug-in socket has a rated voltage of 250V AC with an output rating of 12A." "This plug-in relay socket is compatible with interface plug-in relay RUM range." "It has a large choice of number of contacts for high rated current use with space-saving design which allows for a flexible and easy installation on DIN rail." "It helps to reduce the size of enclosures and increase machine reliability, you can mount nearly everywhere." "It is compatible with plug in control relay." "It enables easy installation and connect to relay from its socket." "Workability for hard-wired logic automated systems to complement the functions of industrial programmable logic controllers (PLCs)."
Specifications
Specifications
| Range of product | Harmony Electromechanical Relays |
| Device short name | RUZ |
| Product or component type | Socket |
| Product compatibility | Plug-in relay RUM with 3 C/O contact |
| [Ith] conventional free air thermal current | 12 A |
| [Ue] rated operational voltage | < 250 V |
| Contacts type and composition | 3 C/O |
| Connections - terminals | Connector, 1 x 0.25...1 x 2.5 mm² (AWG 22...AWG 14) flexible with cable end, Connector, 2 x 0.25...2 x 1 mm² (AWG 22...AWG 17) flexible with cable end, Connector, 1 x 0.5...1 x 2.5 mm² (AWG 20...AWG 14) solid without cable end, Connector, 2 x 0.5...2 x 1.5 mm² (AWG 20...AWG 16) solid without cable end |
| Shape of pin | Cylindrical |
| Tightening torque | < 1 N.m for M3.5 screw(s) |
| Fixing mode | By screw (panel), Clip-on (35 mm symmetrical DIN rail) |
| Contact terminal arrangement | Separate |
| [Uimp] rated impulse withstand voltage | 4 kV |
| Overvoltage category | III |
| Pollution degree | 3 |
| Sale per indivisible quantity | 10 |
| Width | 36 mm |
| Net weight | 0.1 kg |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Standards | IEC 61984 |
| Product certifications | CSA, UL |
| Marking | CE |
| Ambient air temperature for storage | -40…85 °C |
| Ambient air temperature for operation | -40…55 °C |
Packaging
| Package 1 | 1 PCE, 9.600 cm × 6.500 cm × 3.500 cm (L × W × H), 83.000 g |
| Package 2 | 10 BB1, 18.200 cm × 11.000 cm × 10.500 cm (L × W × H), 879.000 g |
| Package 3 | 80 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 7.611 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
RUZSC3M: frequently asked questions
When can RUZSC3M be shipped?
RUZSC3M is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up RUZSC3M in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for RUZSC3M and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for RUZSC3M, subject to availability and destination.
