Schneider Electric NSYCUX1KDG

Side Connected Cooling Unit, Climasys CU, Stainless Steel, 1kW, 230V, 50/60Hz, IP55

MPN
NSYCUX1KDG
EAN
3606486055045
Category
ClimaSys CU
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric NSYCUX1KDG?

"This new Side Connected Cooling Unit, designed by Schneider Electric, is perfectly adapted for Automation & Control and Electrical distribution panels, installed in office and industrial indoor environments." "It’s smart, compact, and reliable. It can be mounted full / half-flush or surface depending on the space available in the panel or in the room." "For international business purpose, it’s compliant to IEC14511 and UL60335-1 & UL60335-2-40." "This cooling device is made by Stainless Steel, offering an internal IP55. Its cooling capacity L35-35 is 1000W according to EN 14511. Its power voltage is 230V, 50/60Hz, 1 phase." "Its native Modbus connectivity is 100% compatible with any Scada system." "Remote alarms and operation data makes manufacturing process more dependable with fewer downtimes, with quicker and easier problem fixing, and electrical components expended lifespan." "The new Connected Cooling Units are also associated with Software’s and Services, like ProClima Web or IGE XAO suits." "By using these tools, in only few minutes, it’s possible to select and optimize one Thermal management solution, and to design one panel (with its enclosures, devices and Thermal solution), with 3D and 2D drawings." "Also, the Schneider Electric EcoStruxure Apps and analytics facilitates process supervision with real life data and action recommendations for more efficient operation and maintenance (preventive and predictive)."

Specifications

Specifications

RangeClimaSys
Product nameCU
mounting typeSide
Product or component typeCooling unit
InstallationIndoor side
Product destinationFor enclosure
Mounting modeBy screws
Supply Voltage220...240 V 1 phase 50 Hz EN/IEC, 230 V +/- 6 % 1 phase 50 Hz UL
Rated Power1000 W
Cooling power1000 W 50/60 Hz L35-L35, 870 W 50/60 Hz L35-L50
Height780 mm
Width345 mm
Depth215 mm
[In] rated current3.0 A
Inrush current6 A
Power consumption in W480 W at 50/60 Hz, L35-L35, 530 W at 50/60 Hz, L35-L50
Energy efficiency ratio2.1
Control typeElectronic controller
Temperature setting range20…50 °C at 50/60 Hz
Ambient air temperature for operation20…50 °C at 50/60 Hz inside the enclosure:, 5…55 °C at 50/60 Hz outside the enclosure:
Noise level70 dB
Pressure30 bar
Flow rateInternal circuit: 550 m3/h at 50/60 Hz, External circuit: 850 m3/h at 50/60 Hz
Net weight22.4 kg
Cooling gas typeR134a (0.145 kg)
Type of filterOptional external circuit filter
Recommended circuit breaker protectionM9F23116
Thermal protection Recommended (fuse)15 A (T)
MaterialStainless steel
ColourStainless steel
Product certificationsUL, IEC, EN
Directives2006/42/EC - machinery, 2014/30/EU - electromagnetic compatibility, 2011/65/EU - RoHS
StandardsEN/ISO 12100, EN 60335-1, EN 60335-2-40, EN 61000-3-2, EN 61000-3-3, EN 61000-6-2, EN 61000-6-3, EN/IEC 63000:2018, EN 14511
IP degree of protectionIP55 conforming to IEC 60529 (on the internal circuit), IP24 conforming to IEC 60529 (on the external circuit)

Packaging

Package 11 PCE, 42.500 cm × 25.500 cm × 87.500 cm (L × W × H), 24.400 kg
Package 27 P12, 120.000 cm × 80.000 cm × 102.000 cm (L × W × H), 182.000 kg

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

NSYCUX1KDG: frequently asked questions

When can NSYCUX1KDG be shipped?

NSYCUX1KDG is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up NSYCUX1KDG in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for NSYCUX1KDG and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYCUX1KDG, subject to availability and destination.
