Home / Schneider Electric / ClimaSys CU / Schneider Electric NSYCUSP003DG

Schneider Electric

Schneider Electric NSYCUSP003DG

Fan kit for Connected Cooling Unit, Climasys CU

MPN: NSYCUSP003DG
Category: ClimaSys CU

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric NSYCUSP003DG?

This Connected Cooling Unit Spare part is composed with 1 Centrifugal fan & 1 capacitor. Its fan power is 80W, with a nominal voltage of 230V. Its air flow is 850m3/h. Its dimensions (HxWxD) are 75 mmx220 mmx220 mm.

Specifications

Range of product	ClimaSys
Product name	CU
Product or component type	Condenser fan kit, Evaporator fan kit
Product destination	Fan for side/top cooling unit 850 W, Ue = 230 V, Side/top cooling unit 1000 W, Side/top cooling unit 1250 W, Side/top cooling unit 1650 W, Side/top cooling unit 2000 W
Offer type	Spare part
Mounting location	Internal
fixing mode	By screw
Device composition	1 fan: inside, 1 capacitor: inside
Operational power in W	80 W
Air flow	850 m3/h
Material	Polyamide 6 with 30 % fibre glass
Colour	Black
Height	75 mm
Width	220 mm
Depth	220 mm
Product certifications	CE, UL
Quantity per set	1

Packaging

Package 1	1 PCE, 33.000 cm × 28.000 cm × 15.000 cm (L × W × H), 2.500 kg
Package 2	4 PAL, 120.000 cm × 45.000 cm × 29.000 cm (L × W × H), 10.000 kg

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet NSYCUSP003DGPDF

NSYCUSP003DG: frequently asked questions

When can NSYCUSP003DG be shipped?

NSYCUSP003DG is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up NSYCUSP003DG in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for NSYCUSP003DG and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYCUSP003DG, subject to availability and destination.
