External condensate evaporator, Climasys CU, for Connected cooling Unit
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | ClimaSys CU |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 2.08 kg |
Shipping & availability
When can NSYCUACC009DG be shipped?
NSYCUACC009DG is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYCUACC009DG in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYCUACC009DG and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYCUACC009DG, subject to availability and destination.
Schneider Electric External condensate evaporator, Climasys CU, for Connected cooling Unit, manufacturer part number NSYCUACC009DG. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Range | ClimaSys |
| Product or component type | Heater and water condensation unit |
| Accessory / separate part category | Cooling accessory |
| Mounting location | Outside the enclosure |
| Accessory / separate part destination | For cooling unit |
| Device composition | 1 heater and water condensation unit: outside sealed area |
| Quantity per set | 1 |
| [Ue] rated operational voltage | 230 V AC (+/- 10 %) |
| Protection type | Thermal protection: T 3 A |
| Evaporation capactity | 250 |
| PTC probe input | Resistance PTC |
| Height | 103 mm |
| Width | 164 mm |
| Depth | 148 mm |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 15.000 cm |
| Package 1 Width | 29.000 cm |
| Package 1 Length | 33.000 cm |
| Package 1 Weight | 2.078 kg |
| Unit Type of Package 2 | PAL |
| Number of Units in Package 2 | 2 |
| Package 2 Height | 29.000 cm |
| Package 2 Width | 45.000 cm |
| Package 2 Length | 120.000 cm |
| Package 2 Weight | 4.156 kg |
| Warranty (in months) | 18 |
