Schneider Electric NSYCAF223DG
ClimaSys - CSVS SmartFilter G3 223x223mm
- MPN
- NSYCAF223DG
- EAN
- 3606489559311
- Category
- ClimaSys CA
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYCAF223DG?
"Set of 5 G2 filters for ClimaSys enclosures" "The product is to be mounted between enclosure and outlet grille or fan" "The width is 212mm" The height is 212mm Compatible with dust sensor NSYCCASFSDUST, NSYCVF,M,DG and NSYCAG,DG The filter is 8mm thick Cut-out dimensions is 223 x 223mm Flame retardance M1 conforming to NF P92-507 and K1/F1 conforming to DIN 53 438 "This product is qualified as a green premium, with minimal use of hazardous substances"
Specifications
Specifications
| Range | ClimaSys |
| Product name | ClimaSys CA |
| Product or component type | Filter |
| Range compatibility | Spacial, Thalassa |
| Accessory / separate part category | Thermal management accessory |
| Type of ventilation filter | G3 EN 779, G3 ISO 16890-1 |
| Mounting location | Between enclosure and outlet grille or fan |
| Product compatibility | Dust sensor NSYCCASFSDUST, NSYCVF...M...DG, NSYCAG...DG |
| Accessory / separate part destination | Outlet grille 268 x 248 mm |
| Quantity per set | Set of 5 |
| Cut-out dimensions | 223 x 223 mm |
| Width | 212 mm |
| Height | 212 mm |
| thickness | 8 mm |
| Flame retardance | M1 conforming to NF P92-507, K1/F1 conforming to DIN 53 438 |
Packaging
| Package 1 | 1 PCE, 22.000 cm × 21.000 cm × 1.000 cm (L × W × H), 13.000 g |
| Package 2 | 5 BB1, 22.000 cm × 21.000 cm × 5.000 cm (L × W × H), 69.000 g |
| Package 3 | 100 CAR, 46.000 cm × 46.000 cm × 32.000 cm (L × W × H), 1.398 kg |
