Schneider Electric ATV452075M – ATV45-2 0.75 kW 200/240V - 3 phases - IP20
Discontinued by Schneider Electric — we can still source the original ATV452075M (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Altivar 45 |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Recommended replacement | ATV320U07M2C |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the ATV452075M now that it is discontinued?
Yes. Schneider Electric has discontinued the ATV452075M, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the ATV320U07M2C as its successor — we can quote both.
When can ATV452075M be shipped?
ATV452075M is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up ATV452075M in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for ATV452075M and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ATV452075M, subject to availability and destination.
Schneider Electric ATV452075M — ATV45-2 0.75 kW 200/240V - 3 phases - IP20. Discontinued by Schneider Electric; the manufacturer's successor is ATV320U07M2C. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Altivar 5 |
| Product or component type | Variable speed drive |
Complementary
| Product destination | Asynchronous motors |
| [Us] rated supply voltage | 200...240 V - 15...10 % |
| Supply frequency | 50...60 Hz - 5...5 % |
| Network frequency limits | 47.5…63 Hz |
| Network number of phases | 3 phases |
| Motor power kW | 0.75 kW |
| Motor power hp | 1 hp |
| Line current | 5 A |
| Continuous output current | 3.6 A |
| Speed drive output frequency | 1…132 Hz |
| Display type | 7 segments |
| Output voltage | <= power supply voltage |
| Physical interface | Serial link |
| Height | 382 mm |
| Width | 239 mm |
| Depth | 170 mm |
Environment
| IP degree of protection | IP20 |
| Ambient air temperature for operation | 0…40 °C |
| Ambient air temperature for storage | -25…70 °C |
| Operating altitude | <= 1000 m; > 1000 m with current derating 3 % per 1000 m |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
| Product data sheet ATV452075M |
