Schneider Electric ATV32HU75N4437 – variable speed drive ATV32 - 7.5kW 400 V - 3P - Bluetooth built-in - w heat sink

Name: Schneider Electric ATV32HU75N4437 – variable speed drive ATV32 - 7.5kW 400 V - 3P - Bluetooth built-in - w heat sink
Brand: Schneider Electric
SKU: ATV32HU75N4437

MPN: ATV32HU75N4437 · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original ATV32HU75N4437 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Altivar 32
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
UPC / EAN	3606480787690
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the ATV32HU75N4437 now that it is discontinued?

Yes. Schneider Electric has discontinued the ATV32HU75N4437, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can ATV32HU75N4437 be shipped?

ATV32HU75N4437 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ATV32HU75N4437 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ATV32HU75N4437 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ATV32HU75N4437, subject to availability and destination.

Schneider Electric ATV32HU75N4437 — variable speed drive ATV32 - 7.5kW 400 V - 3P - Bluetooth built-in - w heat sink (Altivar 32). Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Altivar 32
Product or component type	Variable speed drive
Product destination	Asynchronous motors; Synchronous motors
Product specific application	Complex machines
Function available	Configure over bluetooth
Assembly style	With heat sink
Component name	ATV32
EMC filter	Class C2 EMC filter integrated
Network number of phases	3 phases
[Us] rated supply voltage	380...500 V - 15...10 %
Supply voltage limits	323…550 V
Supply frequency	50...60 Hz - 5...5 %
Network frequency	47.5...63 Hz
Motor power kW	7.5 kW at 380...480 V
Motor power hp	10 hp at 380...480 V

Complementary

Line current	18.7 A for 500 V 3 phases 7.5 kW / 10 hp; 26.5 A for 380 V 3 phases 7.5 kW / 10 hp
Apparent power	22.9 kVA at 500 V 3 phases 7.5 kW / 15 hp
Prospective line Isc	22 kA for 3 phases
Nominal output current	17 A at 4 kHz 500 V 7.5 kW / 10 hp
Maximum transient current	25.5 A for 60 s 7.5 kW / 10 hp
Output frequency	0.0005…0.599 kHz
Nominal switching frequency	4 kHz
Switching frequency	2...16 kHz adjustable
Speed range	1…100 for asynchronous motor in open-loop mode
Speed accuracy	+/- 10 % of nominal slip 0.2 Tn to Tn
Torque accuracy	+/- 15 %
Transient overtorque	170…200 %
Braking torque	<= 170 % with braking resistor
Asynchronous motor control profile	Flux vector control without sensor, standard; Voltage/frequency ratio, 5 points; Flux vector control without sensor - Energy Saving, NoLoad law; Voltage/frequency ratio, 2 points; Voltage/frequency ratio - Energy Saving, quadratic U/f
Synchronous motor control profile	Vector control without sensor
Regulation loop	Adjustable PID regulator
Motor slip compensation	Automatic whatever the load; Not available in voltage/frequency ratio (2 or 5 points); Adjustable 0...300 %
Local signalling	1 LED red for drive voltage; 1 LED blue for bluetooth; 1 LED green for CANopen run; 1 LED red for CANopen error; 1 LED red for drive fault
Output voltage	<= power supply voltage
Noise level	43 dB conforming to 86/188/EEC
Insulation	Electrical between power and control
Electrical connection	Screw terminal, clamping capacity: 0.5...1.5 mm², 18 AWG...14 AWG (control); Removable screw terminals, clamping capacity: 2.5...16 mm², 12 AWG...6 AWG (motor/braking resistor); Screw terminal, clamping capacity: 6...16 mm², 8 AWG...6 AWG (power supply)
Tightening torque	0.5 N.m, 4.4 lb/ft (control); 1.2 N.m, 10.6 lb/ft (motor/braking resistor); 1.2 N.m, 10.6 lb/ft (power supply)
Supply	Internal supply for reference potentiometer (1 to 10 kOhm): 10.5 V DC +/- 5 %, <10 mA, protection type: overload and short-circuit protection
Analogue input number	3
Analogue input type	AI1 voltage: 0...10 V DC, impedance: 30000 Ohm, resolution 10 bits; AI2 bipolar differential voltage: +/- 10 V DC, impedance: 30000 Ohm, resolution 10 bits; AI3 current: 0...20 mA (or 4-20 mA, x-20 mA, 20-x mA or other patterns by configuration), impedance: 250 Ohm, resolution 10 bits
Sampling duration	2 ms (AI1, AI2, AI3) - analog input(s); 2 ms (AO1) - analog input(s)
Response time	LI1...LI6 8 ms, tolerance +/- 0.7 ms for logic output(s); R1A, R1B, R1C 2 ms for relay output(s); R2A, R2C 2 ms for relay output(s)
Accuracy	+/- 0.2 % (AI1, AI2, AI3) for a temperature of -10...60 °C; +/- 0.5 % (AI1, AI2, AI3) for a temperature of 25 °C; +/- 1 % (AO1) for a temperature of 25 °C; +/- 2 % (AO1) for a temperature of -10...60 °C
Linearity error	+/- 0.2...0.5 % of maximum value (AI1, AI2, AI3); +/- 0.3 % (AO1)
Analogue output number	1
Analogue output type	AO1 software-configurable current 0...20 mA, impedance: 800 Ohm, resolution 10 bits; AO1 software-configurable voltage 0...10 V, impedance: 470 Ohm, resolution 10 bits
Discrete output number	3
Discrete output type	Configurable relay logic: (R1A, R1B, R1C) NO/NC - 100000 cycles; Configurable relay logic: (R2A, R2B) NO - 100000 cycles; Logic: (LO)
Minimum switching current	5 mA at 24 V DC for configurable relay logic
Maximum switching current	R1: 3 A at 250 V AC resistive load, cos phi = 1; R1: 4 A at 30 V DC resistive load, cos phi = 1; R1, R2: 2 A at 250 V AC inductive load, cos phi = 0.4; R1, R2: 2 A at 30 V DC inductive load, cos phi = 0.4; R2: 5 A at 250 V AC resistive load, cos phi = 1; R2: 5 A at 30 V DC resistive load, cos phi = 1
Discrete input number	7
Discrete input type	Programmable (sink/source) (LI1...LI4)24...30 V DC, with level 1 PLC; Programmable as pulse input 20 kpps (LI5)24...30 V DC, with level 1 PLC; Switch-configurable PTC probe (LI6)24...30 V DC; Safe torque off (STO)24...30 V DC - 1500 Ohm
Discrete input logic	Negative logic (sink) (LI1...LI6), > 19 V (state 0), < 13 V (state 1); Positive logic (source) (LI1...LI6), < 5 V (state 0), > 11 V (state 1)
Acceleration and deceleration ramps	Ramp switching; S; CUS; U; Deceleration ramp adaptation; Linear; Deceleration ramp automatic stop DC injection
Braking to standstill	By DC injection
Protection type	Input phase breaks: drive; Overcurrent between output phases and earth: drive; Overheating protection: drive; Short-circuit between motor phases: drive; Thermal protection: drive
Communication port protocol	Modbus; CANopen
Connector type	1 RJ45 (on front face) for Modbus/CANopen
Physical interface	2-wire RS 485 for Modbus
Transmission frame	RTU for Modbus
Type of polarization	No impedance for Modbus
Number of addresses	1…127 for CANopen; 1…247 for Modbus
Method of access	Slave CANopen
Electromagnetic compatibility	1.2/50 µs - 8/20 µs surge immunity test, level 3 conforming to IEC 61000-4-5; Conducted radio-frequency immunity test, level 3 conforming to IEC 61000-4-6; Electrical fast transient/burst immunity test, level 4 conforming to IEC 61000-4-4; Electrostatic discharge immunity test, level 3 conforming to IEC 61000-4-2; Radiated radio-frequency electromagnetic field immunity test, level 3 conforming to IEC 61000-4-3; Voltage dips and interruptions immunity test conforming to IEC 61000-4-11
Width	150 mm
Height	308 mm
Depth	232 mm
Net weight	7.5 kg
Option card	Communication card for CANopen daisy chain; Communication card for CANopen open style; Communication card for DeviceNet; Communication card for EtherNet/IP; Communication card for Profibus DP V1
Functionality	Mid
Specific application	Other applications

Environment

Standards	EN/IEC 61800-3; EN 61800-3 environments 2 category C2; EN/IEC 61800-5-1; EN 55011 class A group 1; EN 61800-3 environments 1 category C2
Product certifications	UL; GOST; CSA; C-Tick; NOM 117
Marking	CE
Pollution degree	2 conforming to EN/IEC 61800-5-1
IP degree of protection	IP20 conforming to EN/IEC 61800-5-1
Vibration resistance	1 gn (f = 13…200 Hz) conforming to EN/IEC 60068-2-6; 1.5 mm peak to peak (f = 3…13 Hz) conforming to EN/IEC 60068-2-6
Shock resistance	15 gn for 11 ms conforming to EN/IEC 60068-2-27
Relative humidity	5…95 % without condensation conforming to IEC 60068-2-3; 5…95 % without dripping water conforming to IEC 60068-2-3
Ambient air temperature for operation	-10…50 °C without derating; 50…60 °C with derating factor
Ambient air temperature for storage	-25…70 °C
Operating altitude	<= 1000 m without derating; 1000...3000 m with current derating 1 % per 100 m
Operating position	Vertical +/- 10 degree
