Schneider Electric 140NOC77101

Modicon Quantum Ethernet comunication module - RJ45 - 10/100 Mbit/s

MPN
140NOC77101
EAN
3595864083551
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original 140NOC77101 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 140NOC77101?

Schneider Electric 140NOC77101 — Modicon Quantum Ethernet comunication module - RJ45 - 10/100 Mbit/s. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Quantum automation platform
Product or component typeEthernet communication module

Complementary

Product compatibilityAll Unity CPU
Communication port protocolEtherNet/IP; Modbus TCP
Exchange modeFull duplex
Maximum number of connections128
Transmission rate10/100 Mbit/s
RedundancyNo standalone
Web serverTransparent ready class B30
Communication serviceDHCP/BootP server; Quality of Service (QoS); CIP implicit messaging (I/O communication); SOAP XML Web (client/server); SNMP agent; FDR server; Modbus TCP messaging; CIP Explicit messaging (server and client messaging)
Web servicesData Editor (via PC terminal); Rack viewer
Transmission support mediumTwisted pair
Port EthernetRJ45: 10BASE-T/100BASE-TX
MarkingCE
SupplyVia the power supply of the rack
Local signalling1 LED (green) for communication on the bus (Active); 1 LED (green) for configuration status (Ready); 1 LED (green) for connection speed (100MB); 1 LED (green) for Ethernet network status (link); 1 LED (green/red) for module status (Mod Status); 1 LED (green/red) for network communication status (Net Status); 1 LED (green) for full-duplex mode (Fduplex); 1 LED (green) for transmission activity
Current consumption400 mA at 5 V DC
Module formatStandard
Net weight0.345 kg

Environment

StandardsEN 55011; EN 61131-2; UL 508; CSA C22.2 No 142; FM 3611 Class 1 Division 2; IEEE 802.3
Product certificationsMerchant Navy; ODVA
IP degree of protectionIP20
Ambient air temperature for operation0…60 °C
Relative humidity10…95 % at 60 °C without condensation

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

140NOC77101: frequently asked questions

Can I still buy the 140NOC77101 now that it is discontinued?

Yes. Schneider Electric has discontinued the 140NOC77101, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 140NOC77101 be shipped?

140NOC77101 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140NOC77101 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140NOC77101 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140NOC77101, subject to availability and destination.
