Schneider Electric 140CPU43412UC

Unity processor Modicon Quantum - 1056 kB - 66 MHz - coated

MPN
140CPU43412UC
EAN
3595863839838
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original 140CPU43412UC (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 140CPU43412UC?

Schneider Electric 140CPU43412UC — Unity processor Modicon Quantum - 1056 kB - 66 MHz - coated. Discontinued by Schneider Electric; the manufacturer's successor is BMEP581020H. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Quantum automation platform
Product or component typeUnity processor

Complementary

Clock frequency66 MHz
Number of slots16; 6; 4; 10; 2
Number of racks2 - local rack(s)
Number of distributed I/O station63 station(s) - 1 rack(s) - 3 Modbus Plus network(s)
Number of remote I/O station31 - 2 rack(s) per S908 remote I/O; 0 - 0 rack(s) per ethernet remote I/O
Discrete I/O number31744 inputs, 31744 outputs - remote; 8000 inputs, 8000 outputs - distributed - per network Modbus Plus; Unlimited (26 slots max) - local
Analogue I/O number500 inputs, 500 outputs - distributed - per network Modbus Plus; 1984 inputs,1984 outputs - S908 remote I/O; Unlimited (26 slots max) - local
Application specific I/OHigh-speed interrupt inputs; Counter; Accurate time stamping; Serial link
Number of optional modules6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
Maximum number of connections2 AS-Interface - distributed; 2 Modbus (RS232/485 Modbus/ASCII); 4 AS-Interface - remote; 6 Ethernet TCP/IP - local; 6 Modbus Plus - local; 6 Profibus DP - local
Integrated connection type1 Modbus Plus with; 2 Modbus with
ChecksProcess control
Memory descriptionInternal RAM 1056 kB
Switch functionSlide switch communication port : ASCII/RTU/Memory; Key switch memory start/stop memory protection
Application structure1 cyclic/periodic master task -; 1 periodic fast task -; 16 timer interrupt tasks -; 64 I/O interrupt tasks -; 64 interrupt tasks -; No auxiliary task -
Execution time per instruction0.1...0.27 µs floating points; 0.1...0.27 µs on fixed-point arithmetic; 0.12...0.585 µs Boolean; 0.12...0.585 µs on word
Number of instructions per ms1.86 Kinst/ms 100 % Boolean; 2.49 Kinst/ms 65 % Boolean and 35 % numerical
System overhead0.2 ms for fast task; 1 ms for master task
Bus current requirement1800 mA
Local signalling1 LED (green) for communications are active on the Modbus Plus port (Modbus Plus); 1 LED (green) for communications are active on the Modbus port (Modbus); 1 LED (green) for CPU has been started and is solving logic (RUN); 1 LED (green) for CPU has passed the power-up diagnostic tests (READY); 1 LED (orange) for write-protected memory (memory port); 1 LED (red) for battery needs replacing or is not present (BAT LOW); 1 LED (red) for communications error on the Modbus Plus port (ERROR A)
Electrical connection1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network; 2 female connectors, connector type: SUB-D 9 for connecting to the Modbus bus

Environment

Protective treatmentConformal coating Humiseal 1A33
Product certificationsCSA; CE; UL; Misc (Marine); GOST
StandardsHazLoc

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

140CPU43412UC: frequently asked questions

Can I still buy the 140CPU43412UC now that it is discontinued?

Yes. Schneider Electric has discontinued the 140CPU43412UC, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMEP581020H as its successor — we can quote both.

When can 140CPU43412UC be shipped?

140CPU43412UC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140CPU43412UC in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140CPU43412UC and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140CPU43412UC, subject to availability and destination.
