Schneider Electric 140CPS12400C – power supply module Modicon Quantum - 115 V/230 V AC - redundant

MPN: 140CPS12400C · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original 140CPS12400C (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Modicon Quantum
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Country of origin	FR
UPC / EAN	3595861135987
Recommended replacement	BMXCPS4002H
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the 140CPS12400C now that it is discontinued?

Yes. Schneider Electric has discontinued the 140CPS12400C, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXCPS4002H as its successor — we can quote both.

When can 140CPS12400C be shipped?

140CPS12400C is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140CPS12400C in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140CPS12400C and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140CPS12400C, subject to availability and destination.

Schneider Electric 140CPS12400C — power supply module Modicon Quantum - 115 V/230 V AC - redundant. Discontinued by Schneider Electric; the manufacturer's successor is BMXCPS4002H. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon Quantum automation platform
Product or component type	Power supply module
Power supply type	Redundant

Complementary

Input voltage	115 V (93...138 V) AC 47…63 Hz; 230 V (170...276 V) AC
Input current	1100 mA at 115 V; 600 mA at 230 V
Inrush current	19 A 230 V; 38 A 115 V
rated power in VA	130 VA
Associated fuse rating	2 A, slow-blow
Harmonic distortion	<= 10 % of fundamental rms value
Output voltage	5.1 V DC
Power supply output current	8 A 60 °C redundant
Output overvoltage protection	Internal
Output overload protection	Internal
Power dissipation	6 + (1.5 x Iout) where Iout is in A
Local signalling	1 LED (green) for power (PWR OK)
Marking	CE
Module format	Standard
Net weight	0.65 kg

Environment

Protective treatment	Conformal coating Humiseal 1A33
Standards	CSA C22.2 No 142; UL 508
Product certifications	FM Class 1 Division 2; cUL
Resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2; 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields	10 V/m 80…2000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-40…85 °C
Relative humidity	95 % without condensation
Operating altitude	<= 5000 m
