Allen-Bradley 440R-N23112
Guardmaster MSR126.1T Safety Relay
- MPN
- 440R-N23112
- Category
- Safety Relays Single-Function
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Rockwell Automation / Allen-Bradley parts? We buy surplus →
What is the Allen-Bradley 440R-N23112?
Allen-Bradley 440R-N23112 — Guardmaster MSR126.1T Safety Relay. PartnerPLC supplies new, surplus and discontinued Allen-Bradley parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Active |
| Repair options available | No |
Specifications
| Reset | Automatic/Manual |
| Sub Brand | Guardmaster |
| Category | Up to 4 |
| Continuous safety output current | UL: B300 5A @ 250V AC, 24V DC, AC-15: 6A @ 250V AC, DC-13: 3A @ 24V DC |
| Days of operation | 365 dbays |
| DC avg. (EN ISO 13849-1) | 99 % |
| Depth | 110 mm |
| Electrical life cycle | ops: (with surge suppression) 250V AC/6 A/1500VA cosφ = 1...0.1 M, 250V AC/2.5 A/625VA cosφ = 1...0.5 M, 250V AC/1.5 A/375VA cosφ = 0.35...0.3 M, 250V AC/5 A/1250VA cosφ = 0.6...0.1 M, 24V DC/2 A/48 W = 1 M, 10V DC/0.01 A/0.1 W = 2 M |
| Enclosure protection | IP40 (NEMA 1) |
| Enclosure type | IP40 (NEMA 1), DIN 0470 |
| Evaluation inputs | One- and two-channel |
| Fuses output | External: 6 A slow blow or 10 A fast acting |
| Height | 75 mm |
| Hours of operation | 24 h |
| Immediate safe dry No output | 2 |
| Inductive, AC-15 | 6.0A @ 250V AC |
| Inductive, DC-13 | 6 A/24V DC @ 6 ops/min |
| Input resistance, max | 90 ohm |
| Input simultaneity | Infinite |
| Mission time | 20 year |
| Model | Basic device |
| Mounting | DIN rail: 35 mm |
| MTTFd | 375 year |
| Number of outputs, safety related, delayed, semiconductors | 0 |
| Number of outputs, safety related, delayed, with contact | 0 |
| Number of outputs, safety related, undelayed, semiconductors | 0 |
| Number of outputs, safety related, undelayed, with contact | 2 |
| Number of outputs, signalling function, delayed, semiconductors | 0 |
| Number of outputs, signalling function, delayed, with contact | 0 |
| Number of outputs, signalling function, undelayed, semiconductors | 0 |
| Number of outputs, signalling function, undelayed, with contact | 0 |
| Operating temperature | -5 °C |
| Operating voltage range | 195.5 |
| Performance level | Up to e |
| PFHd | 2.03E-09 |
| Pollution degree | 2 |
| Power consumption | 4 W |
| Power ON delay | 300 ms |
| Rail mounting possible | true |
| Rated control supply voltage at AC 50 Hz | 230 V |
| Rated control supply voltage at AC 60 Hz | 230 V |
| Rated impulse withstand voltage | 2500 V |
| Recovery time | 100 ms |
| Relative humidity | 90% |
| Release delay | false |
| Reset | Automatic/manual |
| Resistive, AC-1 | 6.0A @ 250V AC |
| Resistive, DC-1 | 6.0A @ 24V DC |
| Response time | 15 ms |
| Safety integrity level claim limit | 3 |
| Shock | 10 G, 16 ms, 100 shocks |
| Suitable for monitoring of emergency-stop circuits | true |
| Suitable for monitoring of magnetic switches | true |
| Suitable for monitoring of optoelectronic protection equipment | true |
| Suitable for monitoring of position switches | true |
| Suitable for monitoring of proximity switches | true |
| Suitable for monitoring of tactile sensors | true |
| Suitable for monitoring of valves | true |
| Switching current, min | 10mA @ 10V |
| T cycle | 8/28800 (h/s) |
| Terminal protection | IP20, DIN 0470 |
| Terminal type | Fixed |
| Thermal current (Ith) | Maximum 6 A in one current path (non-switching) |
| Type of electric connection | Screw connection |
| Vibration | 10...55 Hz, 0.35 mm |
| Voltage type for actuating | AC |
| Weight | 24V DC: 160 g (0.35 lb) |
| Width | 22.5 mm |
| Wire size | 0.2...2.5 mm² (24...12 AWG) |
| With detachable clamps | false |
| With feedback circuit | true |
| With muting function | false |
| With start input | true |
No matching specifications
440R-N23112: frequently asked questions
When can 440R-N23112 be shipped?
440R-N23112 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 440R-N23112 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 440R-N23112 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 440R-N23112, subject to availability and destination.
