Allen-Bradley 1762-IA8
MicroLogix 8 Point Digital Input Module
- MPN
- 1762-IA8
- EAN
- 612598207183
- Category
- MicroLogix Expansion I/O Modules
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Rockwell Automation / Allen-Bradley parts? We buy surplus →
What is the Allen-Bradley 1762-IA8?
1762 MicroLogix 1200 System, 8 Point 120 VAC Input Module
Specifications
Product
| Lifecycle | Active mature |
| Repair options available | No |
Specifications
| Class | Progmable Logic Controller |
| Depth | 87 |
| digital input modules | 8 Point 120V AC Input Module |
| Height | 90 |
| I/O Isolation | Isolated |
| I/O Status Indication | LED |
| Module Interfaces | digital |
| Number Of Channels | 8 Point |
| Temperature Rating | 0…55 °C (32…131 °F) |
| Altitude | 2000 m |
| Bus current draw, max | 50mA @ 5V DC (0.25 W) |
| Conducted RF immunity | IEC 1000-4-6: 10V @ 0.15...80MHz |
| Depth | 87 mm |
| Digital inputs configurable | false |
| Digital outputs configurable | false |
| EFT/B immunity | IEC1000-4-4: 2kV @ 5kHz |
| ESD immunity | IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect |
| Hazardous environment class | Class I, Division 2, Hazardous Location, Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213) |
| Heat dissipation, max | 2 W |
| Height | 90 mm |
| IEC input compatibility | Type 1+ |
| Input group to backplane isolation | Verified by one of the following dielectric tests: 1517V AC @ 1s or 2145V DC @ 1s. 132V AC working voltage (IEC Class 2 reinforced insulation) |
| Inrush current, max | 250 mA |
| Isolated groups | Group 1: inputs 0...7 (internally connected commons) |
| Nominal Impedance | 12 kΩ @ 50 Hz |
| Number of commons | 1 |
| Number of digital inputs | 8 |
| Off-state current, max | 2.5 mA |
| Off-state voltage, max | 20V AC |
| ON-state current, max | 16.0mA @ 132V AC, 63 Hz |
| On-state current, min | 5.0mA @ 79V AC, 47 Hz |
| On-state current, nom | 12.0mA @ 120V AC, 60 Hz |
| On-state voltage, min | 79V...132V AC |
| Operating humidity | 5...95% noncondensing |
| Operating temperature | -20 to 65 °C |
| Operating voltage | 79...132V AC @ 47...63Hz |
| Power supply distance rating | 6 (the module may not be more than 6 modules away from the system power supply) |
| Radiated and conducted emissions | EN50081-2: Class A |
| Radiated RF immunity | IEC1000-4-3: 10 V/m, 80...1,000 MHz, 80% Alitude modulation, +900 MHz keyed carrier |
| Redundancy | false |
| Shock | Operating: 30G panel mounted, 3 pulses per axis, Relay ops: 7G |
| Short-circuit protection, outputs available | false |
| Signal delay | On delay: 20.0 ms |
| Storage temperature, min | -40 °C |
| Suitable for safety functions | false |
| Surge transient immunity | IEC1000-4-5: 2 kV common mode, 1kV differential mode |
| Time delay at signal exchange | 20 ms |
| Type of electric connection | Screw connection |
| Type of voltage (input voltage) | AC |
| Vibration | Operating: 10...500 Hz, 5 G, 0.015 in. maximum, peak-to-peak, 2 hr each axis, Relay ops: 1.5 G |
| Voltage category | 100/120V AC |
| Weight | 209 g |
| Width | 40.4 mm |
No matching specifications
1762-IA8: frequently asked questions
When can 1762-IA8 be shipped?
1762-IA8 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1762-IA8 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1762-IA8 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1762-IA8, subject to availability and destination.
