Pilz 774526 – PNOZ XV2.1 3/230VAC 24VDC 2n/o 2n/o t

MPN: 774526 · Brand: Pilz

Price on request

Discontinued by Pilz — we can still source the original 774526 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Time monitoring
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.62 kg

Shipping & availability

Can I still buy the 774526 now that it is discontinued?

Yes. Pilz has discontinued the 774526, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 774526 be shipped?

774526 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 774526 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 774526 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 774526, subject to availability and destination.

Pilz PNOZ XV2.1 3/230VAC 24VDC 2n/o 2n/o t, Pilz order number 774526.

Lifecycle: Pilz has discontinued this product and no longer manufactures it. PartnerPLC sources discontinued Pilz parts — request a quote for availability, or ask us about the current Pilz successor.

Specifications

General data

Product ID (Pilz order number)	774526
Approval	CCC, CE, cULus Listed, EAC (Eurasian), TÜV
Lifecycle	Discontinued (no longer manufactured by Pilz)

Electrical data

Supply voltage (V)	230 V
Type of supply voltage U1	AC
Power consumption AC	7 VA
Power consumption DC	3.5 W
Supply voltage U2	24 V
Type of supply voltage U2	DC

Inputs

Number of inputs

Relay outputs

Utilisation cat. AC/DC1 stand.	EN 60947-4-1
Voltage AC1 safety cont.	240 V
Max. current AC1 safety cont.	5 A
Voltage DC1 safety cont.	24 V
Max. current DC1 safety cont.	4 A
Utilisation cat. AC15/DC13sta.	EN 60947-5-1
Voltage AC15 safety cont.	230 V
Max. current AC15 safety cont.	2 A
Voltage DC13 safety cont.	24 V
Relay contact material	AgSnO2+Au

Environmental data

Climatic suitability to ...	EN 60068-2-78
Ambient temperature	-10 … 55 °C
Humidity rating	93 % r. h. at 40 °C
Condensation permitted?	Not permitted
EMC to standard ...	EN 50081-2, EN 50081-1
Vibration to standard ...	EN 60068-2-6
Clearance & creepage dist. to	VDE 0110-1
Protection type, housing	IP40

Times

Selectable times	0.8, s, 0.7000000000000001, 0.4, 3, 0.3, 0.2, 1.5, 0.1, 1, 2, 0.5, 0.6
Repetition accuracy	2 %

Mechanical data

Mounting position	any
Housing material lower section	PPO UL 94 V0
Housing material front plate	ABS UL 94 V0
Housing material upper part	PPO UL 94 V0
Connection terminal	Screw terminal
Terminal style	fixed
Flex. cond. c/s AWG info	24 - 10 AWG
Height dimension	87 mm
Width dimension	90 mm
Depth dimension	121 mm
Net weight	620 g
Gross weight	650 g

Downloads & documentation

Official documents from Pilz, downloaded directly from the manufacturer.

Data sheets & manuals

Check list: PNOZ X - PNOZsigma

PDF · 1.6 MB

CAD & dimension drawings

CAD 2D drawing (DXF Autodesk Drawing Interchange Format)	ZIP · 0.1 MB
CAD 2D drawing (Portable Document Format (Adobe Acrobat))	PDF · 0.1 MB
CAD 3D model (IGES - Initial Graphics Exchange Spec.)	ZIP · 0.3 MB
CAD 3D model (STEP - Product Model Data)	ZIP · 0.1 MB
Electrical CAD Data: EPLAN P8 Macro	EDZ · 0.1 MB

Certificates (1)

Certificate (EAC) RU-C-DE-HB-B-03002-23

PDF · 1.2 MB

12-month warrantyon all new stock

3-month warrantyon used & refurbished parts

30-day returnsno restocking fee on unused parts

Global shippingFast, tracked delivery worldwide
