Pilz 506408

Q: When can 506408 be shipped?

506408 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Q: Can I pick up 506408 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Q: Is express delivery available?

Yes — mention it when you request a quote for 506408 and we'll include express shipping options in our reply.

Q: My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 506408, subject to availability and destination.

PSEN ma2.1p-31/PSEN2.1-10/LED/6mm/1unit

MPN: 506408
EAN: 4046548066784
Category: PSENmag for electronic relays

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Pilz parts? We buy surplus →

What is the Pilz 506408?

Magnetic safety switch 1 n/o 1 n/c, 4-pin M8 male connector, square design, LED, IP67, switching distance 6 mm, height design 13 mm, PU = 1 sensor with actuator.

Specifications

General data

Product ID (Pilz order number)	506408
Approval	CE, UKCA, cULus Listed, TÜV, EAC (Eurasian)
Sensor principle	magnetic
Coding level to ISO 14119	Low
Classification to EN 60947-5-3	PDDB
Suitable for series connection	yes
unit type	Unit
Lifecycle	Active (current Pilz product)

Electrical data

Supply voltage (V)	24
Type of supply voltage U1	DC
Switching voltage	24

Environmental data

Ambient temperature	-25 … 70 °C
Max. ambient temp. at 2000 m	+70 °C
Climatic suitability standard	IEC 60068-2-30
Humidity rating	93 % r. h. at 40 °C
Perm. operating height ASL	2000 m
EMC to standard ...	EN 60947-5-3
Vibration to standard ...	EN 60947-5-2
Acc. shock to standard1	30g
Pollution degree clear.&creep.	3
Protection type, housing	IP65, IP67

Mechanical data

Type 1 actuator	PSEN 2.1-10
Sensor can be flush-mounted	Yes, follow installation guide
Connection type	M8, 4-pin male
Housing material upper part	PBT
Height dimension	45 mm
Width dimension	26 mm
Depth dimension	13 mm
Net weight	40 g
Gross weight	45 g

Environment

RoHS directive	2011/65/EU, 2015/863/EU
RoHS conformity	yes
RoHS exceptions	yes
RoHS except.s acc. to direct.	7c I
REACh compliance	contains min. 1 SVHC-substance
REACh included substances	Lead oxide
%-part of the pollutant	> 0,1%
CAS No.	1317-36-8
SCIP entry available	yes
WEEE classification (08/2018)	5 devices (feed size < 50cm)

Commercial data

ECLASS version	ECLASS-13
ECLASS Reference Feature	27274401
ETIM Version	ETIM-9.0
ETIM Reference Group	EG000026
ETIM Reference Feature	EC002544
UNSPSC 25	39122205
GTIN	4046548066784
Volume	0 dm3
Harmonized System Code	85365019
Quantity per packaging unit	1
