Pepperl Fuchs TCU1200-* (Intel® Atom Elkhart Lake Processor, Windows 11) – Thin Client Unit (TCU)

MPN: TCU1200-* (Intel® Atom Elkhart Lake Processor, Windows 11) · Brand: Pepperl Fuchs

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Industrial Monitors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can TCU1200-* (Intel® Atom Elkhart Lake Processor, Windows 11) be shipped?

TCU1200-* (Intel® Atom Elkhart Lake Processor, Windows 11) is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up TCU1200-* (Intel® Atom Elkhart Lake Processor, Windows 11) in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for TCU1200-* (Intel® Atom Elkhart Lake Processor, Windows 11) and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TCU1200-* (Intel® Atom Elkhart Lake Processor, Windows 11), subject to availability and destination.

• Modular, lightweight design

• Low-power design with minimal heat dissipation

• VisuNet RM Shell installed

• High connectivity flexibility due to multiple interface options

• Certified for ATEX and IECEx Zone 2/22

• IP66

Thin Client Unit, Modular, lightweight design, Low-power design with minimal heat dissipation, VisuNet RM Shell installed, High connectivity flexibility due to multiple interface options, Certified for ATEX and IECEx Zone 2/22, IP66

Specifications

Hardware

Order code (Pepperl+Fuchs part number)	T233192
Processor	Intel® Atom Elkhart Lake x6211E
RAM	4 GB
Mass storage	64 GByte industrial grade MLC SSD
Lifecycle	Active (current Pepperl+Fuchs product)

Supply

Input voltage	24 V DC ± 10 % (SELV/PELV)
Power consumption	14 W average, 30 W max.

Interface

Interface type

Standard:1 x Ethernet 100/1000BASE-TX (Ex e) or 1 x fiber optic 1000BASE-SX (Multimode) or 1 x fiber optic 1000BASE-LX (Singlemode), 1 x USB 2.0 (Ex e; service port), 2 x USB 1.1 (Ex i; intended for Pepperl+Fuchs keyboard and mouse) Optional:1 x barcode reader interface Pepperl+Fuchs Pscan-D/B (Ex i) "S3": 1 x barcode reader interface for wired 1-D scanners IDM-160-D*, IDM-Z1-160-D-* and base station IDMx61-B-* and IDM-Z1-x61-B-* (Ex i) "S4": 1 x barcode reader interface for wired 2-D Scanner IDM-Z1-260-D-* (Ex i) "S5": 1 x RS-232 interface with Power Supply for miscellaneous devices and peripherals (Ex i) 1 x RS-232 (Ex e) 1 x RS-485 (Ex e) 1 x Ethernet 100/1000Base-TX (Ex e) Bluetooth v4.0, communication distance up to 30 m in open terrain, transmission power +8 dBm, transmission frequency 2.402 ... 2.48 GHz

Directive conformity

Electromagnetic compatibility: Directive 2014/30/EU	EN 61326-1:2013 (industrial locations) ; EN 61000-6-4:2007+A1:2011
RoHS: Directive 2011/65/EU (RoHS)	EN 50581:2012-09

Software

Operating system

VisuNet RM Shell 6 (based on Windows® 11 IoT Enterprise LTSC 2024) Optional: TSJ-: IGEL OS 12 (based on Linux, pre-installed without licence) TSI-: IGEL OS 11 (based on Linux, pre-installed without licence) (pending)

Ambient conditions

Operating temperature	-20 ... 65 °C (-4 ... 149 °F)
Storage temperature	-20 ... 65 °C (-4 ... 149 °F)
Relative humidity	93% at 40°C, non-condensating, according to EN 60068-2-78
Shock resistance	18 shocks 15 g , 11 ms all axis, IEC 60068-2-27
Vibration resistance	10 ... 150 Hz, +/- 0.075 mm , 1g, 10 cycles per axis according to EN60068-2-6

Mechanical specifications

Degree of protection	IP66 ( when mounted on the display unit from Pepperl+Fuchs )
Material: Housing	anodized aluminum
Mass	approx. 4 kg
Dimensions	280 mm x 240 mm x 43 mm

Data for application in connection with hazardous areas

EU-type examination certificate	BVS 16 ATEX E 082 X
Marking	II 3G Ex ec [ib] IIC T4 IP66 Gc [exsign] II 3D Ex tc [ib] IIIC T85°C IP66 Dc
Directive conformity: Directive 2014/34/EU	EN 60079-0:2012+A11:2013, EN 60079-7:2015, EN 60079-11:2012, EN 60079-31:2014

International approvals

IECEx approval	IECEx BVS 16.0060X
Approved for	Ex ec [ib] IIC T4 IP66 GcEx tc [ib] IIIC T85°C IP66 Dc
Standards	IEC 60079-0:2011, IEC 60079-7:2015, IEC 60079-11:2011, IEC 60079-31:2013
