Mitsubishi Electric US-N5SSTE
Mitsubishi Low-voltage switchgear Solid State Contactor
- MPN
- US-N5SSTE
Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original US-N5SSTE (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric US-N5SSTE?
The Mitsubishi Electric US-N5SSTE is a solid State Contactor in the Low-voltage switchgear. Rated Operational Current 5A(Category AC-1) 3 Pole 3-Element Batch Control DC Operated Terminal Covers. Mitsubishi Electric has discontinued it (2025/09 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Low-voltage switchgear |
| Sales status | 2025/09 Discontinued (Mitsubishi Electric) |
| Outline | Rated Operational Current 5A(Category AC-1) 3 Pole 3-Element Batch Control DC Operated Terminal Covers |
Specifications
| Product Specification | For Motor/Heater Loads |
| Rating: Rated Operating Current [A]: JEM(Category AC-1) | 5 |
| Rating: Rated Operating Current [A]: IEC(Category AC-51) | 5 |
| Rating: Applicable Heater Capacity [kW]: 1φ 200V | 1 |
| Rating: Applicable Heater Capacity [kW]: 3φ 200V | 1.7 |
| Rating: Maximum Applicable Motor Capacity [kW]/Maximum Operating Current [A]: 3φ 200V | 0.4/3.2 |
| Rating: Minimum Load Current [mA] | 150 |
| Main Circuit Specifications: No.of Poles/Elements | 3-Pole 2-Element Type |
| Main Circuit Specifications: Control Method | Batch Control Type |
| Main Circuit Specifications: Operating Voltage [V] | AC100 to 240 |
| Main Circuit Specifications: Rated Insulation Voltage [V] | AC250 |
| Main Circuit Specifications: Making Voltage Drop | 1.5V/Phase |
| Main Circuit Specifications: Open Circuit Leakage Current | 15mA or Less(AC240V 60Hz) |
| Main Circuit Specifications: Surge ON Current (60 Hz, 1 Half-Wave Cycle Peak Value) [A] | 160 |
| Main Circuit Specifications: Tolerance I2t(A 2s) | 106 |
| Main Circuit Specifications: Trigger System | Zero Voltage Trigger System |
| Main Circuit Specifications: Making and Breaking Current Capacities [A] | 32 |
| Control Circuit Specifications: Rated Operational Voltage [V] | DC12 to 24V |
| Control Circuit Specifications: Control Circuit Input Current | 20mA(DC12 to 24V) |
| Control Circuit Specifications: Input Impedance | 0.6 to 1.2kΩ |
| Control Circuit Specifications: Closing Voltage | DC9V or Less |
| Control Circuit Specifications: Opening Voltage | DC3V or More |
| Control Circuit Specifications: Response Time | Max. 1ms+1/2 Cycle |
| Control Circuit Specifications: Operation Indicator | LED Indicator(Lights When Operating Voltage Applied) |
| Functions: Terminal Covers | Yes |
| Functions: Wiring Streamlining Terminal | No |
| Mounting Method | Screw Mounting,DIN Rail Mounting |
| Terminal Screw Size: Main Circuit | M3.5 |
| Terminal Screw Size: Control Circuit | M3.5 |
No matching specifications
US-N5SSTE: frequently asked questions
Can I still buy the US-N5SSTE now that it is discontinued?
Yes. Mitsubishi Electric (Factory Automation) has discontinued the US-N5SSTE, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can US-N5SSTE be shipped?
US-N5SSTE is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up US-N5SSTE in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for US-N5SSTE and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for US-N5SSTE, subject to availability and destination.
