US-H30DDHZ Mitsubishi Low-voltage switchgear Solid State Contactor

MPN: US-H30DDHZ · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original US-H30DDHZ (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Low-voltage switchgear – Solid State Contactors
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the US-H30DDHZ now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the US-H30DDHZ, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can US-H30DDHZ be shipped?

US-H30DDHZ is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up US-H30DDHZ in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for US-H30DDHZ and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for US-H30DDHZ, subject to availability and destination.

The Mitsubishi Electric US-H30DDHZ is a solid State Contactor in the Low-voltage switchgear. Rated Operational Current 8A(Category AC-1 Directly mounting to Iron Plate) Without Cooling Fins 2 Pole 2-Element Batch Control DC Operated. Mitsubishi Electric has discontinued it (2025/09 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Low-voltage switchgear
Sales status	2025/09 Discontinued (Mitsubishi Electric)
Outline	Rated Operational Current 8A(Category AC-1 Directly mounting to Iron Plate) Without Cooling Fins 2 Pole 2-Element Batch Control DC Operated

Specifications

Product Specification	For Heater Loads
Rating: Rated Operating Current [A]: JEM（Category AC-1）	8
Rating: Minimum Load Current [mA]	300
Main Circuit Specifications: No.of Poles/Elements	2-Pole 2-Element Type
Main Circuit Specifications: Control Method	Individual Control Type
Main Circuit Specifications: Operating Voltage [V]	AC24 to 480
Main Circuit Specifications: Rated Insulation Voltage [V]	AC500
Main Circuit Specifications: Making Voltage Drop	1.8V/Phase
Main Circuit Specifications: Open Circuit Leakage Current	30mA or Less(AC480V 60Hz)
Main Circuit Specifications: Trigger System	Zero Voltage Trigger System
Control Circuit Specifications: Rated Operational Voltage [V]	DC12 to 24V
Control Circuit Specifications: Control Circuit Input Current	10mA(DC12 to 24V)
Control Circuit Specifications: Input Impedance	1.2 to 2.4kΩ
Control Circuit Specifications: Closing Voltage	DC9V or Less
Control Circuit Specifications: Opening Voltage	DC3V or More
Control Circuit Specifications: Response Time	Max. 1ms+1/2 Cycle
Control Circuit Specifications: Operation Indicator	LED Indicator(Lights When Operating Voltage Applied)
Functions: Terminal Covers	No
Functions: Wiring Streamlining Terminal	No
Mounting Method	Screw Mounting
Terminal Screw Size: Main Circuit	M5
Terminal Screw Size: Control Circuit	M3.5
