Mitsubishi Electric SRLD-T5

Mitsubishi Low-voltage switchgear Contactor Relay

MPN
SRLD-T5
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric SRLD-T5?

The Mitsubishi Electric SRLD-T5 is a contactor Relay in the Low-voltage switchgear. 5-Pole Mechanically Latched Type Terminal Covers(with Wiring Streamlining Terminal). Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
Outline5-Pole Mechanically Latched Type Terminal Covers(with Wiring Streamlining Terminal)

Specifications

Product SpecificationMechanically Latched Type
Rated Insulation Voltage Ui [V]690
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V6
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V3
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V1.5
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V1.2
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V10
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V8
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V5
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC24V3
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC48V1.5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC110V0.6
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC220V0.3
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC24V3
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC48V1.5
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC110V2
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC220V0.8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC24V10
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC48V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC110V5
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC220V1
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC24V10
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC48V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC110V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC220V3
Conventional Free Air Thermal Current [A]10
Minimal Applicable Load20V 3mA
Contact Arrangements (Valid)5NO,4NO1NC,3NO2NC
Making Current Capacity [A]: Category AC-15: AC120V66
Making Current Capacity [A]: Category AC-15: AC240V55
Making Current Capacity [A]: Category AC-15: AC550V33
Breaking Current Capacity [A]: Category AC-15: AC120V66
Breaking Current Capacity [A]: Category AC-15: AC240V55
Breaking Current Capacity [A]: Category AC-15: AC550V33
Mechanical Durability [Mil.Times]50
Electrical Durability [Mil.Times]: Category AC-1550
Electrical Durability [Mil.Times]: Category DC-1350
Switching Frequency [Times/Hour]1200
Operation Coil Properties: Operating VoltageDC Operated
Operation Coil Properties: Inrush Input [VA]Close:90(DC Operated),Trip:180(DC Operated)
Functions: Coil Surge Absorbing FunctionNo
Functions: Terminal CoversYes
Functions: Wiring Streamlining TerminalNo
Mounting MethodScrew Mounting,DIN Rail Mounting
Terminal Screw Size: Control CircuitM3.5
Terminal Screw Size: Operation CoilM3.5

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

SRLD-T5: frequently asked questions

When can SRLD-T5 be shipped?

SRLD-T5 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SRLD-T5 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SRLD-T5 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SRLD-T5, subject to availability and destination.
