SRD-T9 Mitsubishi Low-voltage switchgear Contactor Relay

MPN: SRD-T9 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Low-voltage switchgear – Contactor Relays
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can SRD-T9 be shipped?

SRD-T9 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SRD-T9 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SRD-T9 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SRD-T9, subject to availability and destination.

The Mitsubishi Electric SRD-T9 is a contactor Relay in the Low-voltage switchgear. DC Operated 9-Pole Terminal Covers. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Low-voltage switchgear
Outline	DC Operated 9-Pole Terminal Covers

Specifications

Product Specification	DC Operated
Rated Insulation Voltage Ui [V]	690
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V	6
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V	3
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V	1.5
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V	1.2
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V	10
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V	8
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V	5
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V	5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC24V	3
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC48V	1.5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC110V	0.6
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC220V	0.3
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC24V	3
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC48V	1.5
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC110V	2
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC220V	0.8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC24V	10
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC48V	8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC110V	5
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC220V	1
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC24V	10
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC48V	8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC110V	8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC220V	3
Conventional Free Air Thermal Current [A]	10
Minimal Applicable Load	20V 3mA
Contact Arrangements (Valid)	9NO,7NO2NC,5NO4NC
Making Current Capacity [A]: Category AC-15: AC120V	66
Making Current Capacity [A]: Category AC-15: AC240V	55
Making Current Capacity [A]: Category AC-15: AC550V	33
Breaking Current Capacity [A]: Category AC-15: AC120V	66
Breaking Current Capacity [A]: Category AC-15: AC240V	55
Breaking Current Capacity [A]: Category AC-15: AC550V	33
Mechanical Durability [Mil.Times]	1000
Electrical Durability [Mil.Times]: Category AC-15	50
Electrical Durability [Mil.Times]: Category DC-13	50
Switching Frequency [Times/Hour]	1800
Operation Coil Properties: Operating Voltage	DC Operated
Operation Coil Properties: Power Consumption [W]	3.3(2.2)
Operation Coil Properties: Coil Time Constant [ms]	40(45)
Functions: Coil Surge Absorbing Function	No
Functions: Terminal Covers	Yes
Functions: Wiring Streamlining Terminal	No
Mounting Method	Screw Mounting,DIN Rail Mounting
Terminal Screw Size: Control Circuit	M3.5
Terminal Screw Size: Operation Coil	M3.5
