Mitsubishi Electric SRD-N4CXJHSA

Mitsubishi Low-voltage switchgear Contactor Relay

MPN
SRD-N4CXJHSA
Price and lead time confirmed within 1 business day

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original SRD-N4CXJHSA (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric SRD-N4CXJHSA?

The Mitsubishi Electric SRD-N4CXJHSA is a contactor Relay in the Low-voltage switchgear. DC Operated 4-Pole Large Rated Auxiliary Contacts Terminal Covers(with Wiring Streamlining Terminal). Mitsubishi Electric has discontinued it (2016/01 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
Sales status2016/01 Discontinued (Mitsubishi Electric)
OutlineDC Operated 4-Pole Large Rated Auxiliary Contacts Terminal Covers(with Wiring Streamlining Terminal)

Specifications

Product SpecificationDC Operated Large Rated Auxiliary Contacts
Rated Insulation Voltage Ui [V]660
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V10
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V10
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V5
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V4
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V20
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V16
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V10
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V10
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC24V7
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC48V5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC110V1.2
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC220V0.2
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC24V10
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC48V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC110V5
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC220V1
Conventional Free Air Thermal Current [A]20
Minimal Applicable Load48V 200mA
Contact Arrangements (Valid)4NO,3NO1NC,2NO2NC
Making Current Capacity [A]: Category AC-15: AC120V100
Making Current Capacity [A]: Category AC-15: AC240V100
Making Current Capacity [A]: Category AC-15: AC550V40
Breaking Current Capacity [A]: Category AC-15: AC120V100
Breaking Current Capacity [A]: Category AC-15: AC240V100
Breaking Current Capacity [A]: Category AC-15: AC550V40
Mechanical Durability [Mil.Times]1000
Electrical Durability [Mil.Times]: Category AC-1550
Electrical Durability [Mil.Times]: Category DC-1350
Switching Frequency [Times/Hour]1800
Operation Coil Properties: Operating VoltageDC Operated
Operation Coil Properties: Power Consumption [W]7
Operation Coil Properties: Coil Time Constant [ms]40
Functions: Coil Surge Absorbing FunctionYes
Functions: Terminal CoversYes
Functions: Wiring Streamlining TerminalYes
Mounting MethodScrew Mounting,DIN Rail Mounting
Terminal Screw Size: Control CircuitM3.5
Terminal Screw Size: Operation CoilM3.5

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

SRD-N4CXJHSA: frequently asked questions

Can I still buy the SRD-N4CXJHSA now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the SRD-N4CXJHSA, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can SRD-N4CXJHSA be shipped?

SRD-N4CXJHSA is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SRD-N4CXJHSA in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SRD-N4CXJHSA and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SRD-N4CXJHSA, subject to availability and destination.
