What is the Mitsubishi Electric SR-T5BCLCSA?

The Mitsubishi Electric SR-T5BCLCSA is a contactor Relay in the Low-voltage switchgear. AC Operated 5-Pole Overlap Contact Terminal Covers(with Wiring Streamlining Terminal). Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineAC Operated 5-Pole Overlap Contact Terminal Covers(with Wiring Streamlining Terminal)

Specifications

Product SpecificationAC Operated Overlap Contact
Rated Insulation Voltage Ui [V]690
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V6
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V5
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V3
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V3
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V16
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V12
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V5
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC24V3
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC48V2
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC110V0.5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC220V0.1
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC24V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC48V5
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC110V3
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC220V0.5
Conventional Free Air Thermal Current [A]16
Minimal Applicable Load20V 10mA
Contact Arrangements (Valid)4NO1NC,3NO2NC
Making Current Capacity [A]: Category AC-15: AC120V66
Making Current Capacity [A]: Category AC-15: AC240V55
Making Current Capacity [A]: Category AC-15: AC550V33
Breaking Current Capacity [A]: Category AC-15: AC120V66
Breaking Current Capacity [A]: Category AC-15: AC240V55
Breaking Current Capacity [A]: Category AC-15: AC550V33
Mechanical Durability [Mil.Times]100
Electrical Durability [Mil.Times]: Category AC-1515
Electrical Durability [Mil.Times]: Category DC-1315
Switching Frequency [Times/Hour]1800
Operation Coil Properties: Operating VoltageAC Operated
Operation Coil Properties: Inrush Input [VA]45
Operation Coil Properties: Normal input [VA]7
Operation Coil Properties: Power Consumption [W]2.2
Functions: Coil Surge Absorbing FunctionYes
Functions: Terminal CoversYes
Functions: Wiring Streamlining TerminalYes
Mounting MethodScrew Mounting,DIN Rail Mounting
Terminal Screw Size: Control CircuitM3.5
Terminal Screw Size: Operation CoilM3.5
