Mitsubishi Electric SR-K100JH

Mitsubishi Low-voltage switchgear Contactor Relay

MPN
SR-K100JH
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric SR-K100JH?

The Mitsubishi Electric SR-K100JH is a contactor Relay in the Low-voltage switchgear. AC Operated 10-Pole Large Rated Auxiliary Contacts. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineAC Operated 10-Pole Large Rated Auxiliary Contacts

Specifications

Product SpecificationAC Operated Large Rated Auxiliary Contacts
Rated Insulation Voltage Ui [V]660
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V10
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V10
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V5
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V4
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V20
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V16
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V10
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V10
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC24V5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC48V3
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC110V0.8
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC220V0.2
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC24V10
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC48V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC110V5
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC220V1
Conventional Free Air Thermal Current [A]20
Minimal Applicable Load48V 200mA
Contact Arrangements (Valid)10NO,9NO1NC,8NO2NC,7NO3NC,6NO4NC,5NO5NC
Making Current Capacity [A]: Category AC-15: AC120V100
Making Current Capacity [A]: Category AC-15: AC240V100
Making Current Capacity [A]: Category AC-15: AC550V40
Breaking Current Capacity [A]: Category AC-15: AC120V100
Breaking Current Capacity [A]: Category AC-15: AC240V100
Breaking Current Capacity [A]: Category AC-15: AC550V40
Mechanical Durability [Mil.Times]1000
Electrical Durability [Mil.Times]: Category AC-1550
Electrical Durability [Mil.Times]: Category DC-1350
Switching Frequency [Times/Hour]1800
Operation Coil Properties: Operating VoltageAC Operated
Operation Coil Properties: Inrush Input [VA]50
Operation Coil Properties: Normal input [VA]10
Operation Coil Properties: Power Consumption [W]3
Functions: Coil Surge Absorbing FunctionNo
Functions: Terminal CoversNo
Functions: Wiring Streamlining TerminalNo
Mounting MethodScrew Mounting,DIN Rail Mounting
Terminal Screw Size: Control CircuitM3.5
Terminal Screw Size: Operation CoilM3.5

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

SR-K100JH: frequently asked questions

When can SR-K100JH be shipped?

SR-K100JH is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SR-K100JH in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SR-K100JH and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SR-K100JH, subject to availability and destination.
