Mitsubishi Electric SLD-2xT100

Mitsubishi Low-voltage switchgear Magnetic Contactor

MPN
SLD-2xT100
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric SLD-2xT100?

The Mitsubishi Electric SLD-2xT100 is a magnetic Contactor in the Low-voltage switchgear. Representative rating 100A (Category AC-3 AC200V) Mechanically Latched Type. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineRepresentative rating 100A (Category AC-3 AC200V) Mechanically Latched Type

Specifications

Product SpecificationReversible Mechanically Latched Type
Rated Insulation Voltage Ui [V]690
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V22
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V45
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V45
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V30
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V55
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V55
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V55
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V50
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V100
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC500 to 550V120
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC690V150
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V15
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V30
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V100
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V93
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V75
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V105
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V105
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V85
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V65
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V150
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V150
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC500 to 550V150
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC690V150
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V150
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V150
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC24V93
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC48V60
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC110V40
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC220V30
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC24V93
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC48V90
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC110V80
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC220V50
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC24V93
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC48V93
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC110V80
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC220V50
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC24V93
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC48V93
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC110V93
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC220V70
Main Contact Conventional Free Air Thermal Current [A]150
Main Contact Minimal Applicable Load48V 200mA
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V6
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V3
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V1.5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V1.2
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V10
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V8
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V5
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC24V3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC48V1.5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V0.3
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V10
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC48V8
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC110V5
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC220V1
Auxiliary Contact Conventional Free Air Thermal Current [A]10
Auxiliary Contact Minimal Applicable Load20V 3mA
Contact Arrangements (Valid): Main Contact (Standard)3NO×2
Contact Arrangements (Valid): Auxiliary Contact (Standard)1NO2NC×2
Main Contact Making Current Capacity [A]: Category AC-3: AC220V1050
Main Contact Making Current Capacity [A]: Category AC-3: AC440V1050
Main Contact Making Current Capacity [A]: Category AC-3: AC550V850
Main Contact Making Current Capacity [A]: Category AC-3: AC690V650
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V840
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V840
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V680
Main Contact Breaking Current Capacity [A]: Category AC-3: AC690V520
Mechanical Durability [Mil.Times]25
Electrical Durability [Mil.Times]: Category AC-3 (Japan)25
Electrical Durability [Mil.Times]: Category AC-125
Electrical Durability [Mil.Times]: Category DC2,DC425
Electrical Durability [Mil.Times]: Category DC125
Switching Frequency [Times/Hour]: Category AC-31200
Operation Coil Properties: Operating VoltageDC Operated
Operation Coil Properties: Inrush Input [VA]Close:250(DC Operated),Trip:250(DC Operated)
Functions: Coil Surge Absorbing FunctionClosing coils:Yes(other than DC24V,48V) Opening coils:Yes(other than DC24V,48V)
Functions: Terminal CoversNo
Functions: Wiring Streamlining TerminalNo
Mounting MethodScrew Mounting
Terminal Screw Size: Main Circuit (Power Side)M6
Terminal Screw Size: Main Circuit (Load Side)M6
Terminal Screw Size: Operating CircuitM4
Terminal Screw Size: Operation CoilM4

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

SLD-2xT100: frequently asked questions

When can SLD-2xT100 be shipped?

SLD-2xT100 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SLD-2xT100 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SLD-2xT100 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SLD-2xT100, subject to availability and destination.
