What is the Mitsubishi Electric SHL-V320?

The Mitsubishi Electric SHL-V320 is a magnetic Contactor in the Low-voltage switchgear. Representative rating 320A(Category AC3 AC200V) Mechanically Latched Type Vacuum Type. Mitsubishi Electric has discontinued it (2026/07 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
Sales status2026/07 Discontinued (Mitsubishi Electric)
OutlineRepresentative rating 320A(Category AC3 AC200V) Mechanically Latched Type Vacuum Type

Specifications

Product SpecificationMechanically Latched Type Vacuum Magnetic Contactors
Rated Insulation Voltage Ui [V]1500
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V75
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V150
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V200
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC1000V400
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC1500V600
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V320
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V320
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V320
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC1000V320
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC1500V320
Main Contact Conventional Free Air Thermal Current [A]350
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V0.2
Auxiliary Contact Minimal Applicable Load48V 200mA
Contact Arrangements (Valid): Main Contact (Standard)3NO
Contact Arrangements (Valid): Auxiliary Contact (Standard)2NO2NC
Contact Arrangements (Valid): Auxiliary Contact (Special)4NO4NC
Main Contact Making Current Capacity [A]: Category AC-3: AC220V3200
Main Contact Making Current Capacity [A]: Category AC-3: AC440V3200
Main Contact Making Current Capacity [A]: Category AC-3: AC550V3200
Main Contact Making Current Capacity [A]: Category AC-3: AC1000V3200
Main Contact Making Current Capacity [A]: Category AC-3: AC1500V3200
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V2560
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V2560
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V2560
Main Contact Breaking Current Capacity [A]: Category AC-3: AC1000V2560
Main Contact Breaking Current Capacity [A]: Category AC-3: AC1500V2560
Mechanical Durability [Mil.Times]25
Electrical Durability [Mil.Times]: Category AC-3 (Japan)25
Switching Frequency [Times/Hour]: Category AC-31200
Operation Coil Properties: Operating VoltageAC Operated
Operation Coil Properties: Inrush Input [VA]Close:480(AC Operated),Trip:650(AC Operated)
Functions: Coil Surge Absorbing FunctionClosing Coil: Yes Tripping Coil: No
Functions: Terminal CoversNo
Functions: Wiring Streamlining TerminalNo
Mounting MethodScrew Mounting
Terminal Screw Size: Main Circuit (Power Side)M10
Terminal Screw Size: Main Circuit (Load Side)M10
Terminal Screw Size: Operating CircuitM4
Terminal Screw Size: Operation CoilM4
