Mitsubishi Electric SD-T50BC

Mitsubishi Low-voltage switchgear Magnetic Contactor

MPN
SD-T50BC
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric SD-T50BC?

The Mitsubishi Electric SD-T50BC is a magnetic Contactor in the Low-voltage switchgear. Representative rating 50A (Category AC-3 AC200V) DC Operated Terminal Covers(with Wiring Streamlining Terminal). Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineRepresentative rating 50A (Category AC-3 AC200V) DC Operated Terminal Covers(with Wiring Streamlining Terminal)

Specifications

Product SpecificationDC Operated
Rated Insulation Voltage Ui [V]690
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V11
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V22
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V22
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V22
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V25
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V22
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V27
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V55
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC500 to 550V50
Main Contact Rating [Kw]: Three-Phase Resistive Load (Category AC-1): AC690V60
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V8
Main Contact Rating [Kw]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V16
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V50
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V48
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V38
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V55
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V50
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V38
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V26
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC200 to 240V80
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC400 to 440V80
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC500 to 550V60
Main Contact Rated Operating Current [A]: Three-Phase Resistive Load (Category AC-1): AC690V60
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC100 to 110V80
Main Contact Rated Operating Current [A]: Single-Phase Resistive Load (Category AC-1): AC200 to 220V80
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC24V45
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC48V25
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC110V15
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC220V3.5
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC24V50
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC48V35
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC110V30
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 3-Pole: DC220V12
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC24V50
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC48V40
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC110V35
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 2-Pole: DC220V15
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC24V50
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC48V50
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC110V50
Main Contact Rated Operating Current [A]: DC Resistive Load (Category DC1) 3-Pole: DC220V40
Main Contact Conventional Free Air Thermal Current [A]80
Main Contact Minimal Applicable Load48V 200mA
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V6
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V3
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V1.5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V1.2
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V10
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V8
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V5
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC24V3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC48V1.5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V0.3
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V10
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC48V8
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC110V5
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC220V1
Auxiliary Contact Conventional Free Air Thermal Current [A]10
Auxiliary Contact Minimal Applicable Load20V 3mA
Contact Arrangements (Valid): Main Contact (Standard)3NO
Contact Arrangements (Valid): Auxiliary Contact (Standard)2NO2NC
Main Contact Making Current Capacity [A]: Category AC-3: AC220V550
Main Contact Making Current Capacity [A]: Category AC-3: AC440V500
Main Contact Making Current Capacity [A]: Category AC-3: AC550V380
Main Contact Making Current Capacity [A]: Category AC-3: AC690V260
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V440
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V400
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V304
Main Contact Breaking Current Capacity [A]: Category AC-3: AC690V208
Mechanical Durability [Mil.Times]1000
Electrical Durability [Mil.Times]: Category AC-3 (Japan)200
Electrical Durability [Mil.Times]: Category AC-150
Electrical Durability [Mil.Times]: Category DC2,DC450
Electrical Durability [Mil.Times]: Category DC150
Switching Frequency [Times/Hour]: Category AC-31200
Operation Coil Properties: Operating VoltageDC Operated
Operation Coil Properties: Power Consumption [W]9
Operation Coil Properties: Coil Time Constant [ms]40
Functions: Coil Surge Absorbing FunctionNo
Functions: Terminal CoversYes
Functions: Wiring Streamlining TerminalYes
Mounting MethodScrew Mounting,DIN Rail Mounting
Terminal Screw Size: Main Circuit (Power Side)M5
Terminal Screw Size: Main Circuit (Load Side)M5
Terminal Screw Size: Operating CircuitM3.5
Terminal Screw Size: Operation CoilM3.5

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

SD-T50BC: frequently asked questions

When can SD-T50BC be shipped?

SD-T50BC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SD-T50BC in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SD-T50BC and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SD-T50BC, subject to availability and destination.
