What is the Mitsubishi Electric MSOL-2xT65KP?

The Mitsubishi Electric MSOL-2xT65KP is a magnetic Starter in the Low-voltage switchgear. Representative rating 65A (Category AC-3 AC200V) Mechanically Latched Type Reversible Type 3-Element Thermal Overload Relay. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineRepresentative rating 65A (Category AC-3 AC200V) Mechanically Latched Type Reversible Type 3-Element Thermal Overload Relay

Specifications

Product SpecificationMechanically Latched Type
Rated Insulation Voltage Ui [V]690
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V30
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V30
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V18.5
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V30
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V37
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V30
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V65
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V65
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V45
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V65
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V65
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V60
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V38
Main Contact Conventional Free Air Thermal Current [A]100
Main Contact Minimal Applicable Load48V 200mA
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V6
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V3
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V1.5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V1.2
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V10
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V8
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V5
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC24V3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC48V1.5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V0.3
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V10
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC48V8
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC110V5
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC220V1
Auxiliary Contact Conventional Free Air Thermal Current [A]10
Auxiliary Contact Minimal Applicable Load20V 3mA
Contact Arrangements (Valid): Main Contact (Standard)3NO×2
Contact Arrangements (Valid): Auxiliary Contact (Standard)2NO2NC×2
Main Contact Making Current Capacity [A]: Category AC-3: AC220V650
Main Contact Making Current Capacity [A]: Category AC-3: AC440V650
Main Contact Making Current Capacity [A]: Category AC-3: AC550V600
Main Contact Making Current Capacity [A]: Category AC-3: AC690V380
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V520
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V520
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V480
Main Contact Breaking Current Capacity [A]: Category AC-3: AC690V304
Mechanical Durability [Mil.Times]25
Electrical Durability [Mil.Times]: Category AC-3 (Japan)25
Switching Frequency [Times/Hour]: Category AC-31200
Operation Coil Properties: Operating VoltageAC Operated
Operation Coil Properties: Inrush Input [VA]Close:120(AC Operated),Trip:250(AC Operated)
Protection Mode of Thermal Overload Relay3-element(Overlord, Constraint and Open-phase Protection)
Functions: Coil Surge Absorbing FunctionClosing coils: Yes(other than DC24V,48V) Opening coils: No
Functions: Terminal CoversNo
Functions: Wiring Streamlining TerminalNo
Mounting MethodScrew Mounting, DIN Rail Mounting
Terminal Screw Size: Main Circuit (Power Side)M6
Terminal Screw Size: Main Circuit (Load Side)M6
Terminal Screw Size: Operating CircuitM4
Terminal Screw Size: Operation CoilM4
