Mitsubishi Electric MSOD-Q12BC

Mitsubishi Low-voltage switchgear DC Interface Contactor

MPN
MSOD-Q12BC
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric MSOD-Q12BC?

The Mitsubishi Electric MSOD-Q12BC is a DC Interface Contactor in the Low-voltage switchgear. Representative rating 12A (Category AC-3 AC200V) DC Operated Terminal Covers 2-Element Thermal Overload Relay. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineRepresentative rating 12A (Category AC-3 AC200V) DC Operated Terminal Covers 2-Element Thermal Overload Relay

Specifications

Product SpecificationDC Operated DC Interface Contactors
Rated Insulation Voltage Ui [V]690
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V2.5
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V4
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V4
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V12
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V9
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V7
Main Contact Conventional Free Air Thermal Current [A]20
Main Contact Minimal Applicable Load24V 300mA
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V3
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V1
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V0.6
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V10
Auxiliary Contact Conventional Free Air Thermal Current [A]10
Auxiliary Contact Minimal Applicable Load5V 3mA
Contact Arrangements (Valid): Main Contact (Standard)3NO
Contact Arrangements (Valid): Auxiliary Contact (Standard)1NO1NC
Contact Arrangements (Valid): Auxiliary Contact (Special)2NO
Main Contact Making Current Capacity [A]: Category AC-3: AC220V120
Main Contact Making Current Capacity [A]: Category AC-3: AC440V90
Main Contact Making Current Capacity [A]: Category AC-3: AC550V70
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V96
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V72
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V56
Mechanical Durability [Mil.Times]1000
Electrical Durability [Mil.Times]: Category AC-3 (Japan)100
Switching Frequency [Times/Hour]: Category AC-31800
Operation Coil Properties: Operating VoltageDC Operated
Operation Coil Properties: Power Consumption [W]DC24V Coil:1.3 DC48V Coil:1.65
Operation Coil Properties: Coil Time Constant [ms]10
Protection Mode of Thermal Overload Relay2-element(Overload and Constraint Protection)
Functions: Coil Surge Absorbing FunctionYes
Functions: Terminal CoversYes
Functions: Wiring Streamlining TerminalYes(Thermal only)
Mounting MethodScrew Mounting, DIN Rail Mounting
Terminal Screw Size: Main Circuit (Power Side)M3.5
Terminal Screw Size: Main Circuit (Load Side)M3.5
Terminal Screw Size: Operating CircuitM3.5
Terminal Screw Size: Operation CoilM3.5

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

MSOD-Q12BC: frequently asked questions

When can MSOD-Q12BC be shipped?

MSOD-Q12BC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up MSOD-Q12BC in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for MSOD-Q12BC and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for MSOD-Q12BC, subject to availability and destination.
