Mitsubishi Electric MSO-T25BCKP

Mitsubishi Low-voltage switchgear Magnetic Starter

MPN
MSO-T25BCKP
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric MSO-T25BCKP?

The Mitsubishi Electric MSO-T25BCKP is a magnetic Starter in the Low-voltage switchgear. Representative rating 26A (Category AC-3 AC200V) AC Operated Terminal Covers(with Wiring Streamlining Terminal) 3-Element Thermal Overload Relay. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineRepresentative rating 26A (Category AC-3 AC200V) AC Operated Terminal Covers(with Wiring Streamlining Terminal) 3-Element Thermal Overload Relay

Specifications

Product SpecificationAC Operated
Rated Insulation Voltage Ui [V]690
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V5.5
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V11
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V11
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V7.5
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V15
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V11
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V26
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V25
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V20
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V26
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V26
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V24
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V12
Main Contact Conventional Free Air Thermal Current [A]32
Main Contact Minimal Applicable Load48V 200mA
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V6
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V3
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V1.5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V1.2
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V10
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V8
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V5
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC24V3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC48V1.5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V0.3
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V10
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC48V8
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC110V5
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC220V1
Auxiliary Contact Conventional Free Air Thermal Current [A]10
Auxiliary Contact Minimal Applicable Load20V 3mA
Contact Arrangements (Valid): Main Contact (Standard)3NO
Contact Arrangements (Valid): Auxiliary Contact (Standard)2NO2NC
Main Contact Making Current Capacity [A]: Category AC-3: AC220V300
Main Contact Making Current Capacity [A]: Category AC-3: AC440V300
Main Contact Making Current Capacity [A]: Category AC-3: AC550V240
Main Contact Making Current Capacity [A]: Category AC-3: AC690V120
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V240
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V240
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V192
Main Contact Breaking Current Capacity [A]: Category AC-3: AC690V96
Mechanical Durability [Mil.Times]1000
Electrical Durability [Mil.Times]: Category AC-3 (Japan)200
Switching Frequency [Times/Hour]: Category AC-31800
Operation Coil Properties: Operating VoltageAC Operated
Operation Coil Properties: Inrush Input [VA]75
Operation Coil Properties: Normal input [VA]7
Operation Coil Properties: Power Consumption [W]2.4
Protection Mode of Thermal Overload Relay3-element(Overlord, Constraint and Open-phase Protection)
Functions: Coil Surge Absorbing FunctionNo
Functions: Terminal CoversYes
Functions: Wiring Streamlining TerminalYes
Mounting MethodScrew Mounting, DIN Rail Mounting
Terminal Screw Size: Main Circuit (Power Side)M4
Terminal Screw Size: Main Circuit (Load Side)M4
Terminal Screw Size: Operating CircuitM3.5
Terminal Screw Size: Operation CoilM3.5

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

MSO-T25BCKP: frequently asked questions

When can MSO-T25BCKP be shipped?

MSO-T25BCKP is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up MSO-T25BCKP in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for MSO-T25BCKP and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for MSO-T25BCKP, subject to availability and destination.
