Mitsubishi Electric MSO-N18CXKPSA
Mitsubishi Low-voltage switchgear Magnetic Starter
- MPN
- MSO-N18CXKPSA
Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original MSO-N18CXKPSA (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric MSO-N18CXKPSA?
The Mitsubishi Electric MSO-N18CXKPSA is a magnetic Starter in the Low-voltage switchgear. Representative rating 18A (Category AC-3 AC200V) AC Operated Terminal Covers(with Wiring Streamlining Terminal) 3-Element Thermal Overload Relay. Mitsubishi Electric has discontinued it (2015/10 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Low-voltage switchgear |
| Sales status | 2015/10 Discontinued (Mitsubishi Electric) |
| Outline | Representative rating 18A (Category AC-3 AC200V) AC Operated Terminal Covers(with Wiring Streamlining Terminal) 3-Element Thermal Overload Relay |
Specifications
| Product Specification | AC Operated |
| Rated Insulation Voltage Ui [V] | 690 |
| Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | 3.7 |
| Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | 5.5 |
| Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V | 5.5 |
| Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V | 4.5 |
| Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V | 7.5 |
| Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V | 7.5 |
| Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V | 7.5 |
| Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | 18 |
| Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | 13 |
| Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V | 13 |
| Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V | 18 |
| Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V | 16 |
| Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V | 13 |
| Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC690V | 9 |
| Main Contact Conventional Free Air Thermal Current [A] | 25 |
| Main Contact Minimal Applicable Load | 48V 200mA |
| Contact Arrangements (Valid): Main Contact (Standard) | 3NO |
| Main Contact Making Current Capacity [A]: Category AC-3: AC220V | 180 |
| Main Contact Making Current Capacity [A]: Category AC-3: AC440V | 160 |
| Main Contact Making Current Capacity [A]: Category AC-3: AC550V | 130 |
| Main Contact Making Current Capacity [A]: Category AC-3: AC690V | 90 |
| Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V | 144 |
| Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V | 128 |
| Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V | 104 |
| Main Contact Breaking Current Capacity [A]: Category AC-3: AC690V | 72 |
| Mechanical Durability [Mil.Times] | 1000 |
| Electrical Durability [Mil.Times]: Category AC-3 (Japan) | 200 |
| Switching Frequency [Times/Hour]: Category AC-3 | 1800 |
| Operation Coil Properties: Operating Voltage | AC Operated |
| Operation Coil Properties: Inrush Input [VA] | 45 |
| Operation Coil Properties: Normal input [VA] | 7 |
| Operation Coil Properties: Power Consumption [W] | 2.4 |
| Protection Mode of Thermal Overload Relay | 3-element(Overlord, Constraint and Open-phase Protection) |
| Functions: Coil Surge Absorbing Function | Yes |
| Functions: Terminal Covers | Yes |
| Functions: Wiring Streamlining Terminal | Yes |
| Mounting Method | Screw Mounting, DIN Rail Mounting |
| Terminal Screw Size: Main Circuit (Power Side) | M4 |
| Terminal Screw Size: Main Circuit (Load Side) | M4 |
| Terminal Screw Size: Operation Coil | M3.5 |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
MSO-N18CXKPSA: frequently asked questions
Can I still buy the MSO-N18CXKPSA now that it is discontinued?
Yes. Mitsubishi Electric (Factory Automation) has discontinued the MSO-N18CXKPSA, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can MSO-N18CXKPSA be shipped?
MSO-N18CXKPSA is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up MSO-N18CXKPSA in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for MSO-N18CXKPSA and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for MSO-N18CXKPSA, subject to availability and destination.
