ME96SSRB-MB Mitsubishi Power monitoring MODBUS RTU

MPN: ME96SSRB-MB · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Power monitoring – Meters
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can ME96SSRB-MB be shipped?

ME96SSRB-MB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ME96SSRB-MB in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ME96SSRB-MB and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ME96SSRB-MB, subject to availability and destination.

The Mitsubishi Electric ME96SSRB-MB is a MODBUS RTU in the Power monitoring. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Power monitoring
Category	MODBUS RTU

Specifications

Category	Electrical Indicators
Group	Electronic Multi-Measuring Instrument
Model	ME96 series standard model
Model name	ME96SSRB-MB
Phase wire system	3-phase 4-wire, 3-phase 3-wire (3CT, 2CT), 1-phase 3-wire, 1-phase 2-wire (common use)
Rating: Current	5A AC, 1A AC (common use)
Rating: Voltage	3-phase 4-wire : max 277/480V AC 3-phase 3-wire : (DELTA) max 220V AC, (STAR) max 440V AC 1-phase 3-wire : max 220/440V AC 1-phase 2-wire : (DELTA) max 220V AC, (STAR) max 440V AC
Rating: Frequency	50/60Hz (common use)
Measuring element: Current (A): Measuring Item	A1, A2, A3, AN, A AVG
Measuring element: Current (A): Class	±0.2%
Measuring element: Current demand (DA): Measuring Item	DA1, DA2, DA3, DAN, DA AVG
Measuring element: Current demand (DA): Class	±0.2%
Measuring element: Voltage (V): Measuring Item	V12, V23, V31, V AVG (L-L), V1N, V2N, V3N, V AVG (L-N)
Measuring element: Voltage (V): Class	±0.2%
Measuring element: Active power (W): Measuring Item	W1, W2, W3, ΣW
Measuring element: Active power (W): Class	±0.5%
Measuring element: Reactive power (var): Measuring Item	var1, var2, var3, Σvar
Measuring element: Reactive power (var): Class	±0.5%
Measuring element: Apparent power (VA): Measuring Item	VA1, VA2, VA3, ΣVA
Measuring element: Apparent power (VA): Class	±0.5%
Measuring element: Power factor (PF): Measuring Item	PF1, PF2, PF3, ΣPF
Measuring element: Power factor (PF): Class	±0.5%
Measuring element: Frequency (Hz): Measuring Item	Hz
Measuring element: Frequency (Hz): Class	±0.1%
Measuring element: Active energy (Wh): Measuring Item	Imported, Exported
Measuring element: Active energy (Wh): Class	class 0.5S (IEC62053-22)
Measuring element: Reactive energy (varh): Measuring Item	Imported lag, Imported lead, Exported lag, Exported lead
Measuring element: Reactive energy (varh): Class	class 1S (IEC62053-24)
Measuring element: Apparent energy (VAh): Measuring Item	Imported + Exported
Measuring element: Apparent energy (VAh): Class	±2.0%
Measuring element: Harmonic current (HI): Measuring Item	Total, 1 st to 19 st (Odd degree only)
Measuring element: Harmonic current (HI): Class	±1.0%
Measuring element: Harmonic voltage (HV): Measuring Item	Total, 1 st to 19 st (Odd degree only)
Measuring element: Harmonic voltage (HV): Class	±1.0%
Measuring element: Rolling demand active power (DW): Measuring Item	Rolling block, Fixing block (Select either of them according to the settings.)
Measuring element: Rolling demand active power (DW): Class	±0.5%
Measuring element: Rolling demand reactive power (Dvar): Measuring Item	Rolling block, Fixing block (Select either of them according to the settings.)
Measuring element: Rolling demand reactive power (Dvar): Class	±1.0%
Measuring element: Rolling demand apparent power (DVA): Measuring Item	Rolling block, Fixing block (Select either of them according to the settings.)
Measuring element: Rolling demand apparent power (DVA): Class	±1.0%
Measuring element: Periodic active energy (Wh): Measuring Item	Periodic active energy 1, Periodic active energy 2, Periodic active energy 3
Measuring element: Periodic active energy (Wh): Class	class 0.5S
Measuring element: Operating time (h): Measuring Item	Operating time 1, Operating time 2
Measuring element: Operating time (h): Class	(Reference)
Measuring element: Current unbalance rate (Aunb): Measuring Item	Aunb
Measuring element: Current unbalance rate (Aunb): Class	(Reference)
Measuring element: Voltage unbalance rate (Vunb): Measuring Item	Vunb
Measuring element: Voltage unbalance rate (Vunb): Class	(Reference)
Measuring element: CO 2 equivalent: Measuring Item	kg
Measuring element: CO 2 equivalent: Class	(Reference)
Measuring method: Instantaneous value	A, V: RMS value calculation; W, var, VA, Wh, varh, VAh: Digital multiplication; PF: Power ratio calculation; Hz: Zero-cross; HI, HV: FFT
Measuring method: Demand value	DA: Thermal type calculation, DW, Dvar, DVA: Rolling demand calculation
Display: Display type	LCD with LED backlight
Display: Number of display digits or segments: Digital section	First to third line indication: 4 digits, Fourth line indication: 6 digits A, DA, V, W, var, VA, PF, DW, Dvar, DVA: 4 digits; Hz: 3 digits; Wh, varh, VAh: 9 digits (6-digit or 12-digit is also available.); Harmonic distortion ratio/content rate: 4 digits; Harmonic RMS value: 4 digits; Operating time: 6 digits or 9-digit; Digital input/output: I/O
Display: Display update time interval	0.5s, 1s (selectable)
Transmission function: Transmission type	MODBUS RTU
Transmission function: Transmission speed	2400, 4800, 9600, 19200, 38400bps
Transmission function: Connection method	Multi-drop
Transmission function: Transmission distance	1,200m (max)
Transmission function: Number of connectable units	31 units
Built-in logging: Logging mode	Automatic overwrite update
Built-in logging: Logging data type: Measuring data	Measuring data and time data are logged at the interval set at the data logging period. (15 min, 30 min, 60 min) * Integrated values (Wh, varh, and VAh) are measured values of ME96SS. They are not differential values by logging period.
Built-in logging: Logging data type: Alarm log	Time data at alarm generating/cancellation and at waiting for alarm cancellation
Built-in logging: Logging data type: The recorded time of the Max/Min value	Max/Min value data and time data
Built-in logging: Number of logging items: Measuring data	Integrated value data: 5 items, Data other than integrated value: 15 items, Total: A maximum of 20 items
Built-in logging: Number of logging items: Alarm log	The number of the set alarms
Built-in logging: Number of logging items: The recorded time of the Max/Min value	The total is 19 items: Current Max/Min (AVG), Line voltage Max/Min (AVG), Phase voltage Max/Min (AVG), Total active power Max/Min (AVG), Total power factor Max/Min (AVG), Frequency Max/Min (AVG), Total reactive power Max/Min, Total apparent power Max/Min, Total harmonic current RMS Max value, Harmonic line voltage distortion ratio Max total, Harmonic phase voltage distortion ratio Max total
Built-in logging: Internal memory logging period: Measuring data	30 days (Logging period: 15 minutes), 60 days (Logging period: 30 minutes), 120 days (Logging period: 60 minutes)
Built-in logging: Internal memory logging period: Alarm log	100 records
Built-in logging: Internal memory logging period: The recorded time of the Max/Min value	1 record for every Max/Min value factor
Built-in logging: System log data	100 records
Built-in logging: Saving logging data	Use of nonvolatile memory
Built-in logging: How to acquire logging data	Acquire the logging data via MODBUS RTU Communication
Built-in logging: Clock accuracy	±1 minute per month, typical
Connectable Optional Plug-in Module	ME-4210-SS96B, ME-0040C-SS96, ME-0052-SS96, ME-0000MT-SS96, ME-0000BU-SS96, ME-0000BU25-SS96
Power interruption backup	Use of nonvolatile memory (Items: settings, MAX/MIN value, active energy, reactive energy, apparent energy, periodic active energy, rolling demand, operating time)
Power interruption backup: Built-in logging	Use of nonvolatile memory (Setup value, Logging data, System log data)
VA Consumption: Voltage circuit	Each phase: 0.1VA (at 110V AC), 0.2VA (at 220V AC), 0.4VA (at 440V AC)
VA Consumption: Current circuit	Each phase: 0.1VA (5A AC)
VA Consumption: Auxiliary power circuit	13VA (at 110V AC), 14VA (at 220V AC), 9W (at 100V DC)
Auxiliary power	100V to 240V AC (±15%), 100V to 240V DC (-30% +15%)
Weight	0.5 kg
Dimensions	96 (H) × 96 (W) × 90 (D) mm
Mounting method	Embedded
Operating temperature	-5°C to +55°C (Daily average temperature: 35°C or less)
Operating humidity	0% to 85% RH, Non condensing
Storage temperature	-25°C to +75°C (Daily average temperature: 35°C or less)
Storage humidity	0% to 85% RH, Non condensing

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Electronic Multi-Measuring Instrument User's Manual :Digest version (MODEL:ME96SSHB-MB / ME96SSRB-MB / ME96SSEB-MB) (IB63E69-G)	PDF · 1.37MB
Electronic Multi-Measuring Instrument User's Manual : Detailed Edition (MODEL:ME96SSRB-MB) (IB63E74-C)	PDF · 7.39MB
Electronic Multi-Measuring Instrument ME series MODBUS Interface specifications (LSPM0075-H)	PDF · 5.42MB
Electronic Multi-Measuring Instrument Programming Manual (CC-Link) For ver.1 remote device station (LEN080334-E)	PDF · 3.98MB
Electronic Multi-Measuring Instrument Programming Manual (CC-Link) For ver.2 remote device station (LEN130391-B)	PDF · 2.51MB
