Mitsubishi Electric GT14-RS2T4-9P
Mitsubishi GOT HMI Communication unit
- MPN
- GT14-RS2T4-9P
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric GT14-RS2T4-9P?
The Mitsubishi Electric GT14-RS2T4-9P is a communication unit in the GOT HMI. RS-232/485 signal conversion For connecting the RS-232 (D-Sub 9-pin connector) and RS-485 (terminal block). Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | GOT HMI |
| Outline | RS-232/485 signal conversion For connecting the RS-232 (D-Sub 9-pin connector) and RS-485 (terminal block) |
Specifications
| Model | GT14-RS2T4-9P |
| Category | Communication units |
| Product name | RS-232/485 signal conversion adapter |
| Series name | GOT2000/GOT1000 |
| Uses | GOT multi-drop connection, Multi-channel function, Temperature controller connection, MODBUS ® /RTU connection |
| Supported model | GT2505-VTBD, GT1455-QTBDE, GT1450-QMBDE, GT1450-QLBDE, GT1455-QTBD, GT1450-QMBD, GT1450-QLBD |
| Remarks | Option units manufactured from October 2026 onward will not be covered by the warranty when used with the discontinued GOT1000 series. For the details, please refer to the Production Discontinuation of Main Units and Some Option Units in the GOT1000 Series for Overseas (GOT-A-0095) |
Specifications
| Operating ambient temperature | 0 to 55°C |
| Storage ambient temperature | -20 to 60°C |
| Operating ambient humidity | 10 to 90%RH, non-condensing |
| Storage ambient humidity | 10 to 90%RH, non-condensing |
| Operating atmosphere | Must be free of lamp black, corrosive gas, flammable gas, or excessive amount of electro conductive dust particles and must not be exposed to direct sunlight (during operation and storage). |
| Power consumption | 0.5 W or less (100 mA/5 V DC), supplied from the GOT |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- GT14-RS2T4-9P RS-232/485 Signal Conversion Adapter User's Manual (JY997D44401)
- GOT2000 Series User's Manual (Hardware) (SH-081194ENG-AW)
- GOT2000系列 主机使用说明书(硬件篇) (SH-081202CHN-AW)
- GOT2000 Series Connection Manual (Mitsubishi Electric Products) For GT Works3 Version1 (SH-081197ENG-BA)
- GOT2000系列 连接手册(三菱电机机器连接篇) 对应GT Works3 Version1 (SH-081205CHN-BA)
- GOT2000 Series Connection Manual (Non-Mitsubishi Electric Products 1) For GT Works3 Version1 (SH-081198ENG-AU)
- GOT2000系列 连接手册(其他公司机器连接篇1) 对应GT Works3 Version1 (SH-081206CHN-AU)
- GOT2000 Series Connection Manual (Non-Mitsubishi Electric Products 2) For GT Works3 Version1 (SH-081199ENG-AQ)
- GOT2000系列 连接手册(其他公司机器连接篇2) 对应GT Works3 Version1 (SH-081207CHN-AP)
- GOT2000 Series Connection Manual (Microcomputers, MODBUS/Fieldbus Products, Peripherals) For GT Works3 Version1 (SH-081200ENG-AS)
GT14-RS2T4-9P: frequently asked questions
When can GT14-RS2T4-9P be shipped?
GT14-RS2T4-9P is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up GT14-RS2T4-9P in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for GT14-RS2T4-9P and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for GT14-RS2T4-9P, subject to availability and destination.
