GT05-MEM-4GC Mitsubishi GOT HMI Option
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi GOT HMI – Options |
| Lifecycle | Active mature |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can GT05-MEM-4GC be shipped?
GT05-MEM-4GC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up GT05-MEM-4GC in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for GT05-MEM-4GC and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for GT05-MEM-4GC, subject to availability and destination.
The Mitsubishi Electric GT05-MEM-4GC is a option in the GOT HMI. CF card 4 GB [GOT1000] For GOT [GOT2000] For GT27-MMR-Z. Mitsubishi Electric has announced its discontinuation (2027/09 To be discontinued) — plan spares now; PartnerPLC also sources it on the surplus market after the end of order. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | GOT HMI |
| Sales status | 2027/09 To be discontinued (Mitsubishi Electric) |
| Outline | CF card 4 GB [GOT1000] For GOT [GOT2000] For GT27-MMR-Z |
Specifications
| Model | GT05-MEM-4GC |
| Category | Option |
| Product name | CF card |
| Series name | GOT2000/GOT1000 |
| Memory capacity | 4 GB |
| Number of write times | 300,000 times |
| Weight | 0.01 kg (0.03 lb) |
| Supported model | [GOT2000: For GT27-MMR-Z] GT27 (Excluding GT2705-VTBD.) [GOT1000: For GOT] GT16, GT16 Handy GOT |
| Remarks -1 | A CF card with more than 2 GB can be used for the GT16 with the following versions of OSes installed. • Boot OS version: 05.09.00AF or later • Standard monitor OS version: 05.09.00 or later If the above versions of OSes are not installed, install the OSes to the GOT by using GT Designer3 Version1.15R or later. |
| Remarks -2 | When formatting a CF card with more than 2 GB by using a personal computer, format the CF card to FAT32. |
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
| GOT1000 Series CF Card/Memory Card Adaptor User's Manual (IB-0800302E-N) | PDF · 0.29MB |
| GOT2000 Series User's Manual (Hardware) (SH-081194ENG-AW) | PDF · 13.15MB |
