What is the Kuka 405656?
Kuka KR 12 R850 Z400, manufacturer part number 405656. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Maximum payload | 12 kg |
| Rated payload | 6 kg |
| Maximum reach | 850 mm |
| Mounting position | Floor |
| Pose repeatability (ISO 9283) | 0.025 mm |
| Number of axes | 4 |
| Ambient temperature during operation | 0 °C to 42 °C (273 K to 315 K) |
| Ambient temperature during stor./transp. | -25 °C to 55 °C (248 K to 328 K) |
| Protection rating (IEC 60529) | IP20 |
| A1 | 400 °/s |
| A2 | 660 °/s |
| A4 | 2700 °/s |
405656: frequently asked questions
When can 405656 be shipped?
405656 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 405656 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 405656 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 405656, subject to availability and destination.
