What is the Kuka 363374?
Kuka KP3-V2H500 R600 L1800-2, manufacturer part number 363374. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Number of axes | 3 |
| Rated payload | 500 kg |
| Loading height | 950 mm |
| Tool radius | 600 mm |
| Mounting position | Floor |
| Ambient temperature during operation | 0 °C to 55 °C (273 K to 328 K) |
| Ambient temperature during stor./transp. | -40 °C to 60 °C (233 K to 333 K) |
| Protection rating (IEC 60529) | IP67 |
| Hollow shaft diameter A1 | 140 mm |
| Hollow shaft diameter counterbearing A2 | 68 |
| Hollow shaft diameter counterbearing A3 | 68 mm |
| Distance between face plates | 1800 mm |
| Pose repeatability A1 | 0.0023 mm |
| Pose repeatability A2 | 0.009 mm |
| Pose repeatability A3 | 0.009 mm |
| A1 | ±185 ° |
| A1 with ES | ±185 ° |
| A2 | Alternativtext wird verwendet! |
| A2 with ES | ±190 ° |
| A3 with ES | ±190 ° |
| Turning time 180° A1 | 3.6 s |
| Turning time 180° A2 | 2.5 s |
| Turning time 180° A3 | 2.5 s |
| Turning time 360° A2 | 4.2 s |
| Turning time 360° A3 | 4.2 s |
363374: frequently asked questions
When can 363374 be shipped?
363374 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 363374 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 363374 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 363374, subject to availability and destination.
