Kuka 313909

MPN: 313909
Category: Positioner, 1-axis

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Kuka 313909?

Kuka KP1-H2600 R1230 HW, manufacturer part number 313909. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Number of axes	1
Rated payload	2600 kg
Loading height	max. 1230 mm
Tool radius	max. 900 mm
Mounting position	Floor
Ambient temperature during operation	0 °C to 55 °C (273 K to 328 K)
Ambient temperature during stor./transp.	0 °C to 55 °C (273 K to 328 K)
Protection rating (IEC 60529)	IP65
Hollow shaft diameter A1	135 mm
Pose repeatability A1	0.015 mm
A1	±1800 °
A1 with ES	±185 °
Turning time 180° A1	3.8 s
Turning time 360° A1	7.6 s
