Kuka 294834

MPN: 294834
Category: Positioner, 3-axis

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Kuka 294834?

Kuka KP3-V2H500 S, manufacturer part number 294834. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Number of axes	3
Rated payload	500 kg
Loading height	max. 950 mm
Tool radius	500 mm to 1000 mm, in 100 mm steps
Mounting position	Floor
Ambient temperature during operation	5 °C to 40 °C (278 K to 313 K)
Ambient temperature during stor./transp.	-40 °C to 60 °C (233 K to 333 K)
Protection rating (IEC 60529)	IP67
Distance between face plates	1600 mm to 3000 mm, in 200 mm steps
Pose repeatability A1	0.0023 mm
Pose repeatability A2	0.009 mm
Pose repeatability A3	0.009 mm
A1	±185 °
A1 with ES	±185 °
A2	Alternativtext wird verwendet!
A2 with ES	±185 °
A3	Alternativtext wird verwendet!
A3 with ES	±185 °
Turning time 180° A2	1.7 s
Turning time 180° A3	1.7 s
Turning time 360° A2	2.7 s
Turning time 360° A3	2.7 s
