Kuka 294698

MPN: 294698
Category: KP2-HV HW

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Kuka 294698?

Kuka KP2-HV1100 HW, manufacturer part number 294698. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Number of axes	2
Rated payload	1100 kg
Loading height	max. 1085 mm
Mounting position	Floor
Ambient temperature during operation	0 °C to 55 °C (273 K to 328 K)
Ambient temperature during stor./transp.	0 °C to 55 °C (273 K to 328 K)
Protection rating (IEC 60529)	IP65
Hollow shaft diameter A1	80 mm
Hollow shaft diameter A2	135 mm
Pose repeatability A1	0.027 mm
Pose repeatability A2	0.015 mm
A1	115 ° / 0 °
A1 with ES	115 ° / 0 °
A2	±1800 °
A2 with ES	±185 °
Turning time 180° A1	10.8 s
Turning time 180° A2	2.5 s
Turning time 360° A1	21.4 s
Turning time 360° A2	4.5 s
