Kuka 204385

LBR iiwa 14 R820

MPN: 204385
Category: LBR iiwa

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Kuka 204385?

Kuka LBR iiwa 14 R820, manufacturer part number 204385. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Rated payload	14 kg
Maximum reach	820 mm
Mounting position	Floor
Pose repeatability (ISO 9283)	0.15 mm
Number of axes	7
Ambient temperature during operation	5 °C to 45 °C (278 K to 318 K)
Ambient temperature during stor./transp.	-25 °C to 70 °C (248 K to 343 K)
Protection rating (IEC 60529)	IP54
Prot. rating, in-line wrist (IEC 60529)	IP54
A1	57 °/s
A2	57 °/s
A3	75 °/s
A4	75 °/s
A5	144 °/s
A6	135 °/s
A7	135 °/s

204385: frequently asked questions

When can 204385 be shipped?

204385 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 204385 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 204385 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 204385, subject to availability and destination.
